Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2200 x 300 x 1000 mm | |
|---|---|---|
| Planter trough internal depth | 200 mm | |
| Planter trough internal width | 2100 mm | |
| Plinth base height | 50 mm | |
| Wavy panel peak-to-valley depth | 80 mm | |
| Per-wave facade panel width | 730 mm | |
| Planter trough internal height | 180 mm | |
| Base contact footprint width | 2180 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Unit net weight | 40 kg | |
|---|---|---|
| Static vertical load on planter trough | 60 kg | |
| Freestanding lateral stability load | 30 kg | |
| Planter water containment capacity | 35 L | |
| Recommended plant quantity | 5 | |
| Structural warranty period | 3 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Front facade panels | 18mm MDF substrate with light oak wood veneer, vertical grain finish | |
|---|---|---|
| Plinth base | 18mm MDF with matte dark black laminate finish | |
| Side and rear enclosure panels | 15mm MDF with matching light oak veneer | |
| Planter trough liner | 1.5mm HDPE waterproof plastic liner, removable | |
| Internal support frame | 20mm x 40mm solid pine wood battens | |
| Base leveler feet | M8 nylon adjustable leveler feet, 15mm adjustment range | |
| Surface finish | Matte UV-cured clear lacquer, abrasion resistance class 2 | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Space division function | Low-height visual partition for open office, lobby, or cafe zoning without full privacy | |
|---|---|---|
| Integrated planting function | Full-length top trough holds live potted plants or direct planting with drainage support | |
| Removable liner design | HDPE liner lifts out for easy planting, watering, and cleaning without moving the full partition | |
| Freestanding installation | No wall anchoring required, weighted base provides stable placement on flat hard floors | |
| Level adjustment function | Adjustable nylon feet compensate for 15mm of floor unevenness to eliminate wobble | |
| Scratch-resistant surface | UV lacquer finish resists scuffs from incidental contact in high-traffic public areas | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open office zoning | Separates collaborative work zones from walkways while maintaining sightlines across the space | |
|---|---|---|
| Commercial lobby decor | Placed against feature walls as decorative greenery element for entryways or reception waiting areas | |
| Cafe and co-working space division | Defines semi-private seating nooks in casual hospitality or shared work environments | |
| Indoor corridor screening | Hides unsightly utility areas or empty wall segments along public office corridors | |
| Healthcare waiting area use | Serves as soft, low barrier between waiting seats with greenery to reduce patient stress |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
