PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1230 × 440 × 830 mm
top surface usable area	1180 x 400 mm
raised back gallery height	60 mm
single drawer internal dimensions	550 x 370 x 120 mm
single drawer front panel size	560 x 180 mm
lower cabinet door opening width	1080 mm total
single door glass inset panel size	340 x 420 mm
internal cabinet compartment height	480 mm
plinth base height	60 mm
adjustable shelf thickness	18 mm
door frame wood thickness	18 mm
top panel thickness	25 mm
Carcass Panel Thickness	25 mm
Back Panel Thickness	9 mm
Door / Drawer Front Thickness	22 mm
Shelf Thickness	25 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

cabinet net weight	42 kg
top surface static load capacity	60 kg
total enclosed storage volume	0.24 m³
hinge door opening angle	110 degrees
drawer slide cycle rating	50000 open/close cycles
door hinge cycle rating	80000 open/close cycles
Shelf Distributed Load	30 kg/shelf
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Angle / Life	165°; 80000 cycles
Anti-tip Fixing Reference	Products above 1200 mm should use at least 2 wall fixing points

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

cabinet carcass	18mm thick engineered wood MDF core with walnut veneer
top surface	25mm thick engineered wood with walnut veneer, clear urethane scratch-resistant coating
door glass panels	4mm thick clear tempered safety glass inset in wood door frames
drawer and door handles	120mm long black powder-coated curved metal bar pulls
drawer slides	Side-mount cold-rolled steel drawer slides with soft-close damping
door hinges	Concealed cold-rolled steel cabinet hinges with 110-degree opening angle
adjustable interior shelves	18mm thick engineered wood with matching walnut edge banding
plinth base	18mm thick engineered wood kick panel with matching walnut finish
back panel	3mm thick hardboard with wood grain finish
edge banding	1mm thick PVC edge banding matching walnut finish
Edge Band Thickness	2 mm
Primary Connector Specification	Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

upper drawer storage	Two equal-width independently operating drawers for small loose item storage
lower cabinet access	Two hinged doors with clear glass panels for visible, dust-protected storage
interior shelf adjustment	Two removable shelves adjust to 3 height positions to accommodate tall items
back gallery retention	Curved raised lip along full rear edge of top surface prevents items from falling against wall
soft-close drawer action	Drawers retract with damped motion to prevent slamming and reduce noise
anti-tip wall anchoring	One wall anchor bracket included to secure cabinet to wall and prevent tipping
plinth base clearance	Closed solid base blocks dust accumulation under cabinet and elevates unit off floor
surface protection coating	Clear urethane top coat resists minor scratches and water rings from daily use
Cable / Vent Opening Reference	If fitted, 80 mm diameter

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons
Reference Packaging Volume	0.65 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

residential entryway use	Suitable for entryway storage of keys, mail, and everyday accessories
dining room sideboard use	Works as a dining buffet for tableware, linens, and serving piece storage
living room display storage	Ideal for living room media adjacent or accent storage for books and decor items
home office file storage	Accommodates office supplies, files, and equipment in home office settings
kitchen supplementary storage	Provides extra kitchen storage for dry goods, small appliances, and serving ware
target user group	Designed for residential users seeking mid-century modern style enclosed storage

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 14749:2016	Safety and performance requirements for domestic storage furniture and kitchen worktops
EN 12150-1:2015	Thermally toughened soda lime silicate glass for building use, applicable to door glass panels
EN 717-1:2004	Formaldehyde emission determination for wood-based panels, E1 class recommended for indoor air quality

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to dimensional and structural quality inspection
GB/T 4897-2015	Particleboard performance requirements, applicable if engineered wood core uses particleboard substrate
GB 18584-2001	Indoor decoration material formaldehyde emission limit for wooden furniture, mandatory for indoor residential use

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural quality inspection;
2. GB/T 4897-2015: Particleboard performance requirements, applicable if engineered wood core uses particleboard substrate;
3. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wooden furniture, mandatory for indoor residential use;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · LSC-WN-2D2G-083

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · LSC-WN-2D2G-083

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · LSC-WN-2D2G-083Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Walnut Finish Freestanding Low Storage Cabinet with 2 Drawers and Glass Doors (model LSC-WN-2D2G-083) is an unbranded mid-century modern storage piece designed for residential use. Its low, streamlined profile sits at 830 mm tall, with an overall footprint of 1230 x 440 mm, featuring a continuous 60 mm raised curved back gallery along the full rear edge of the 1180 x 400 mm usable top surface. The front elevation balances two equal-sized upper drawer fronts, each 560 x 180 mm, above two inset hinged doors fitted with 340 x 420 mm clear tempered glass panels, unified by a flush solid plinth base that creates a clean, unbroken visual line at floor level. Construction centers on durable engineered wood cores: the cabinet carcass, plinth kick panel, and adjustable interior shelves use 18 mm thick material, while the 25 mm thick top surface is finished with a clear urethane scratch-resistant coating, all clad in a consistent walnut wood-grain veneer. Doors feature 4 mm thick clear tempered safety glass set in matching wood frames, fitted with 120 mm long black powder-coated curved metal bar pulls shared with the soft-close drawers. Side-mount cold-rolled steel drawer slides carry a 50000 open/close cycle rating, while concealed cold-rolled steel hinges open to 110 degrees with an 80000 open/close cycle rating. The 3 mm hardboard back panel matches the wood-grain finish, and an included anti-tip wall anchor bracket secures the unit to wall surfaces. Functional design supports flexible, organized storage: two independent upper drawers, each with 550 x 370 x 120 mm internal space, hold small loose items, while the lower cabinet offers 0.24 m³ of total enclosed, dust-protected storage behind glass doors that allow clear visibility of contents. Two removable interior shelves adjust across 3 height positions to accommodate tall items, with each shelf supporting 30 kg of distributed weight; the top surface holds 60 kg of static load. The closed plinth base blocks dust accumulation under the unit, while the back gallery prevents items placed on top from sliding against the wall, and soft-close drawer damping eliminates slamming and operational noise. This cabinet adapts to multiple residential spaces: it serves as entryway storage for keys, mail, and daily accessories, a dining room sideboard for tableware, linens and serving pieces, a living room accent or media-adjacent storage unit for books and decor, a home office storage piece for supplies and files, or supplementary kitchen storage for dry goods and small appliances. Procurement teams and residential buyers should note the unit ships across cartons for a total packaged gross weight of 100 kg, with an 40 minute assembly time per set. The 42 kg net weight freestanding unit does not require permanent installation beyond the provided anti-tip anchor, and fits seamlessly in spaces calling for warm walnut-toned modern enclosed storage.
