Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1500 x 500 x 900 mm | |
|---|---|---|
| back splash height | 100 mm | |
| side splash height | 100 mm | |
| countertop thickness | 25 mm | |
| tambour door section width | 1000 mm | |
| open shelf section width | 500 mm | |
| open shelf vertical clearance (per tier) | 320 mm | |
| base plinth height | 50 mm | |
| internal closed compartment shelf spacing | 350 mm | |
| side panel thickness | 18 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| unit net weight | 52 kg | |
|---|---|---|
| countertop static load capacity | 60 kg | |
| recommended user capacity | 5users | |
| laminate surface abrasion resistance | 2000 cycles | |
| tambour door slide cycle rating | 10000 cycles | |
| product warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| cabinet carcass | 18mm E0-grade particleboard with off-white matte laminate | |
|---|---|---|
| countertop | 25mm MDF core with light oak woodgrain laminate, rounded edge | |
| tambour doors | Rigid PVC with light oak vertical ribbed woodgrain finish, matching track hardware | |
| open shelf surfaces | 18mm particleboard with off-white matte laminate finish | |
| base plinth | 18mm MDF with matching light oak woodgrain laminate | |
| splash guard panels | 18mm particleboard with off-white matte laminate, rounded top edges | |
| shelf support hardware | Zinc-plated steel shelf pins with anti-slip stoppers | |
| tambour door tracks | Powder-coated cold-rolled steel curved tracks | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| sliding tambour door access | Two ribbed doors slide horizontally along hidden tracks to fully open/close 2/3 of storage | |
|---|---|---|
| open shelf storage | Two-tier right-side compartment holds frequently accessed items without door operation | |
| integrated splash guard | Continuous raised rear and right-side lip prevents items from sliding off countertop back/side | |
| floor leveling adjustment | Concealed adjustable feet under base plinth compensate for uneven office floors | |
| countertop equipment support | Flat reinforced top surface supports printers, scanners and small office appliances | |
| closed compartment concealment | Tambour doors fully enclose stored items to maintain a tidy visual appearance in open offices | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| open office work zones | Positioned alongside workstations to store shared supplies, printers and documents | |
|---|---|---|
| executive private offices | Placed against a wall to hold office equipment and reference materials | |
| copy and print rooms | Dedicated surface for printer placement with adjacent storage for paper and toner | |
| small team collaboration areas | Stores meeting supplies, reference materials and shared equipment near collaborative spaces | |
| reception back-of-house areas | Conceals administrative supplies while providing a countertop for guest material preparation |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for structural strength and stability verification | |
|---|---|---|
| EN 14073-3:2004 | Office storage furniture stability and strength test methods, recommended for commercial grade acceptance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard, applicable for shelf load, door cycle and stability testing for office use |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability and finish quality of this office storage unit | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, recommended E0 grade acceptance for indoor office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability and finish quality of this office storage unit; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, recommended E0 grade acceptance for indoor office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
