PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1200 × 500 × 1100 mm
Carcass Panel Thickness	25 mm
Back Panel Thickness	9 mm
Door / Drawer Front Thickness	22 mm
Shelf Thickness	25 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Cabinet net weight	58 kg
Shelf distributed static load	45 kg
Total cabinet distributed load	120 kg
Top tray distributed load	35 kg
File binder capacity	48 standard lever-arch files
Leveling adjustment per glide	15 mm
Door cycle target	50,000 cycles
Hinge and track service load	25 kg moving door mass
Recommended floor loading	2.0 kPa
Shelf Distributed Load	30 kg/shelf

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Cabinet carcass	0.8 mm cold-formed steel sheet with welded or folded corner frame and powder-coated silver-grey finish
Tambour doors	Rigid white thermoplastic or steel-backed slatted tambour panels running in horizontal tracks
Internal shelf	25 mm steel shelf with folded edge profile and four-point side support
Locking hardware	Keyed cam lock with central meeting-stile engagement and two supplied keys
Base glides	Four black polymer-and-steel leveling glides mounted to the cabinet base
Surface finish	Smooth silver-grey powder coating on frame and white coated or polymer door face

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Tambour door operation	Two horizontal sliding doors retract along side tracks, reducing front swing clearance in walkways.
Central locking	Keyed lock secures both doors at the central meeting stile and controls access to the lower compartment.
Shelf adjustment	One internal shelf repositions on side-panel supports at 32 mm pitch for mixed binder and box storage.
Floor leveling	Four adjustable glides raise the plinth 70 mm and correct floor variation up to 15 mm.

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons
Reference Packaging Volume	0.65 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Office document storage	Suitable for open-plan offices, admin areas and copy rooms where locked lower storage and quick-access top staging are required.
Walkway-adjacent placement	Horizontal tambour doors make it suitable for corridors or tight workpoints because no outward door swing is needed.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · LSC-1200W-TAMBOUR-LOCK

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · LSC-1200W-TAMBOUR-LOCK

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · LSC-1200W-TAMBOUR-LOCKOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Low Lockable Tambour Storage Cabinet combines compact, low-level storage with space-saving horizontal doors and a clean commercial appearance. Its silver-grey steel frame is paired with white rigid tambour doors, creating a neutral form suited to coordinated office interiors. The cabinet layout provides a lower enclosed storage area behind two sliding tambour doors, together with an open top compartment that can serve as a convenient staging surface or quick-access tray. This arrangement makes the unit useful for both secured records and regularly handled materials. Construction is based on a cold-formed steel carcass with welded or folded corner framing and a smooth powder-coated finish. The carcass panels and adjustable internal shelf are 25 mm thick, while the back panel is 9 mm thick and the tambour door fronts are 22 mm thick. The tambour panels use rigid thermoplastic or steel-backed slatted sections running in horizontal tracks. Inside, a single steel shelf features a folded edge profile and four-point side support. The cabinet has a net weight of 58 kg and is fitted with four black polymer-and-steel leveling glides. Designed for practical daily use, the two tambour doors retract along side tracks rather than swinging outward, reducing the clearance required in walkways and tight workpoints. A keyed cam lock engages both doors at the central meeting stile and secures the lower compartment; two keys are supplied. The internal shelf can be repositioned on side-panel supports at a 32 mm pitch, allowing flexible storage for binders, boxes, and office supplies. Rated shelf capacity supports distributed static loading up to 45 kg, total cabinet loading up to 120 kg, and top tray loading up to 35 kg. The cabinet can accommodate 48 standard lever-arch files. Leveling glides raise the plinth 70 mm and compensate for floor variation up to 15 mm per glide. This cabinet is well suited to open-plan offices, administrative areas, copy rooms, corridors, and space-constrained workpoints where locked lower storage and accessible top storage are needed. Its low profile also supports placement alongside desks, counters, or circulation routes without demanding door-swing space. Procurement teams should plan for handling and site preparation based on the supplied split packaging information, with reference logistics noting 40 minutes of assembly time per set, 0.65 cubic metres of packaging volume, and a packaged gross weight of 100 kg per set. Buyers should verify the latest package count and delivery details before ordering, particularly for multi-unit projects, and should consider floor condition, required shelf layout, key management, and access route width during specification.

Low Lockable Tambour Storage Cabinet Specifications
