Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 800 x 1050 mm | |
|---|---|---|
| Work surface thickness | 50 mm | |
| Knee clearance width at opening | 600 mm | |
| Knee clearance height under work surface | 700 mm | |
| Knee clearance depth from front edge | 450 mm | |
| Edge band thickness on work surface | 2 mm | |
| Metal support frame wall thickness | 1.5 mm | |
| LED light strip height from floor | 20 mm | |
| Individual curved storage door width | 850 mm | |
| Storage compartment internal depth | 350 mm | |
| Top trim thickness | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net product weight | 160 kg | |
|---|---|---|
| Work surface static load capacity | 150 kg | |
| Per storage cabinet shelf static load | 30 kg | |
| Cabinet hinge open/close cycle rating | 80000 cycles | |
| LED strip operational lifespan | 50000 hours | |
| Recommended maximum user capacity | 1 receptionist | |
| Surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Exterior cabinet panels | 18 mm MDF substrate with brushed bronze metallic PU paint finish | |
|---|---|---|
| Central divider and interior accents | 18 mm MDF substrate with burl wood veneer finish | |
| Work surface top | 25 mm high-density particleboard core with matte laminate | |
| Internal support frame | 1.5 mm thick powder-coated square steel tubing | |
| Perimeter LED lighting | Cool white SMD 2835 LED strip with frosted diffuser cover | |
| Storage door hardware | Soft-close concealed hinges with push-to-open mechanism | |
| Bottom edge trim | Polished stainless steel base trim with integrated light channel | |
| Internal storage shelves | 15 mm thick melamine-faced particleboard, adjustable height | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Ambient base lighting | Full-perimeter cool white LED strip, wall-plug powered for continuous operation | |
|---|---|---|
| Storage access | Two push-to-open handleless curved doors, no external pulls for seamless facade | |
| Seated work access | Central Y-shaped knee opening for unobstructed leg room for one receptionist | |
| Cable management | Two 60 mm diameter desktop cable grommets with under-desk cable tray | |
| Door operation | Soft-close hinges that dampen closing to prevent slamming and reduce noise | |
| Customization support | Custom length, LED color temperature and logo panel options available for commercial projects | |
| Surface maintenance | Non-porous painted/laminated surfaces that wipe clean with standard commercial disinfectants | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Total shipment volume | 3.5 CBM | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Corporate office lobbies | Sleek modern aesthetic suits professional reception areas for visitor greeting | |
|---|---|---|
| Hotel and boutique front desks | Low-profile ambient lighting creates upscale welcoming guest check-in experience | |
| Salon and wellness spa reception | Smooth seamless facade is easy to clean and supports point-of-sale placement | |
| Clinic and medical office check-in | Rounded edges reduce injury risk and non-porous surfaces support sanitization | |
| Small retail checkout counters | Compact single-station layout supports transaction processing and supply storage |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables safety and strength requirements for work surface and structure | |
|---|---|---|
| EN 15372:2016 | Furniture for non-domestic seating and tables durability requirements for high-traffic use | |
| EN 13501-1:2018 | Fire reaction classification for furniture materials, minimum Class E required for public spaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel substrate construction | |
|---|---|---|
| GB/T 3327-2017 | Stability and strength requirements for desks, applicable to work surface load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor commercial use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel substrate construction; 2. GB/T 3327-2017: Stability and strength requirements for desks, applicable to work surface load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor commercial use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
