Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 800 x 400 x 800 mm | |
|---|---|---|
| Single door panel width | 398 mm | |
| Single door panel height | 760 mm | |
| Top surface overhang | 10 mm | |
| Internal compartment clear width | 760 mm | |
| Internal compartment clear depth | 360 mm | |
| Adjustable shelf count | 2 | |
| Lower storage compartment height | 360 mm | |
| Leveling foot height | 20 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total cabinet static load capacity | 225 kg | |
|---|---|---|
| Hinge open-close cycle rating | 80000 cycles | |
| Door hinge maximum opening angle | 110 degrees | |
| Leveling foot adjustment range | 15 mm | |
| Net product weight | 38 kg | |
| Scratch-resistant surface abrasion rating | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet body panels | 18 mm thick E1-grade melamine-faced particleboard, walnut woodgrain finish | |
|---|---|---|
| Contrasting top surface | 25 mm thick light neutral matte melamine laminate, scratch-resistant coating | |
| Cabinet back panel | 5 mm thick hardboard, secured with staples to cabinet rear frame | |
| Internal adjustable shelf | 18 mm thick matching melamine particleboard, with metal shelf supports | |
| Door hinges | Cold-rolled steel concealed soft-close hinges, nickel-plated finish | |
| Integrated lock | Zinc alloy keyed cam lock, with black plastic escutcheon | |
| Leveling feet | Injection-molded nylon base with steel threaded screw, black finish | |
| Edge banding | 1 mm thick PVC edge banding, color-matched to cabinet walnut finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Keyed door locking mechanism | Single cam lock secures both doors simultaneously to prevent unauthorized access | |
|---|---|---|
| Adjustable interior shelving | Middle shelf supports 3 height positions at 50 mm increments to accommodate varied item heights | |
| Floor level adjustment | Four threaded leveling feet rotate independently to level cabinet on uneven flooring | |
| Soft-close door operation | Concealed hinges include damping to close doors quietly without slamming | |
| Dual-side storage access | Two full-height hinged doors open to expose full internal compartment width for easy item retrieval | |
| Multi-purpose top surface | Flat scratch-resistant top supports office printers, decor or document stacks with stable weight rating | |
| Anti-tip safety feature | Wall anchor bracket included to secure cabinet to wall and prevent forward tipping | |
| Lock mounting height from floor | 720 mm | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Office side storage placement | Positioned alongside workstations or executive desks to store files, supplies and personal items | |
|---|---|---|
| Printer stand application | Supports desktop printers or multifunction devices on top with internal paper supply storage | |
| Reception area storage | Placed in reception or waiting areas to store brochures, office supplies and reception materials | |
| Home office use | Suitable for home workspaces to store documents, office equipment and personal work items | |
| Tea and break room storage | Used in office break areas to store cups, dry goods and small kitchen supplies | |
| Under-window storage placement | Low 800 mm height fits under standard office windows without blocking natural light |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to stability and strength testing | |
|---|---|---|
| EN 312:2010 | Performance classification for particleboard used in load-bearing furniture components |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, required minimum E1 grade for indoor office use | |
| GB/T 4897.3-2003 | Performance requirements for particleboard used in furniture structural applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural inspection; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, required minimum E1 grade for indoor office use; 3. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture structural applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
