Automatic mm / inch conversion · Core engineering specifications
| Overall 3-door unit dimensions | 1200 x 400 x 950 mm | |
|---|---|---|
| Overall 2-door unit dimensions | 1000 x 400 x 950 mm | |
| Carcass panel thickness | 16 mm | |
| Door panel thickness | 18 mm | |
| Edge band thickness | 1 mm | |
| Interior shelf count (per unit) | 2 ea | |
| Door clearance opening width | 380 mm (per door) | |
| Top trim thickness | 50 mm | |
| Base trim height | 30 mm | |
| Adjustable shelf height increment | 32 mm | |
| Back panel thickness | 3 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total unit static load capacity | 120 kg | |
|---|---|---|
| Door hinge open/close cycle rating | 80000 cycles | |
| Door opening angle | 110 degrees | |
| Surface scratch resistance | 2000 revolutions | |
| 2-door unit net weight | 35 kg | |
| Available finish color count | 4 | |
| Product warranty period | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass substrate | 16mm melamine laminated particleboard | |
|---|---|---|
| Door panel substrate | 18mm MDF with textured wood grain veneer | |
| Door surface finish | Matte water-based paint | |
| Frame trim material | Powder-coated dark gray aluminum alloy | |
| Back panel material | 3mm hardboard (HDF) | |
| Shelf material | 16mm melamine laminated particleboard | |
| Hinge hardware | Cold-rolled steel with soft-close damper | |
| Edge banding | 1mm PVC matching door and carcass finish | |
| Anti-tip hardware | Zinc-plated steel wall anchor brackets | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Handleless door operation | Push-to-open/rebound mechanism | |
|---|---|---|
| Soft-close door damping | Integrated hinge buffer slows door closure in final 15 degrees | |
| Adjustable interior shelving | Shelf pins support repositioning shelves at 32mm increments | |
| Modular configuration | 2-door and 3-door units align side-by-side for continuous storage runs | |
| Wall anti-tip anchoring | Two included steel brackets secure cabinet to wall studs | |
| Leveling adjustment | Adjustable feet at base corners compensate for uneven floors | |
| Surface cleaning compatibility | Non-porous matte finish supports wiping with standard household/office cleaners | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Office open plan storage | Suitable for placement along office walls for document and supply storage | |
|---|---|---|
| Home living room side storage | Suitable for use as a minimalist credenza for media and household items | |
| Hotel public area storage | Suitable for lobby or lounge storage of amenities and collateral | |
| Modular continuous storage runs | Combine 2-door and 3-door units to match available wall length | |
| Executive office storage | Suitable for placement behind executive desks for private file and material storage | |
| Home entryway storage | Suitable for entryway storage of shoes, bags and everyday items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic and kitchen storage furniture, applicable for structural stability | |
|---|---|---|
| EN 13986:2004+A1:2015 | Wood-based panels for construction, applicable for panel material performance acceptance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for cabinet structural integrity and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E1 grade panel acceptance | |
| GB/T 4893.8-2013 | Furniture surface abrasion resistance test method, applicable for door finish durability validation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for cabinet structural integrity and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E1 grade panel acceptance; 3. GB/T 4893.8-2013: Furniture surface abrasion resistance test method, applicable for door finish durability validation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
