Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1000 x 500 x 950 mm | |
|---|---|---|
| Support foot height | 100 mm | |
| Top overhang projection | 25 mm | |
| Single door width | 490 mm | |
| Single door height | 800 mm | |
| Internal storage clear height | 790 mm | |
| Internal storage clear width | 960 mm | |
| Internal storage clear depth | 460 mm | |
| Ground clearance under base | 90 mm | |
| Door panel corrugation rib depth | 8 mm | |
| Carcass side panel thickness | 0.8 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total internal storage volume | 350 L | |
|---|---|---|
| Uniform shelf static load capacity | 50 kg | |
| Door hinge cycle rating | 20000 open/close cycles | |
| Weather resistance rating | IPX3 | |
| Coating corrosion resistance | 500 hours salt spray | |
| Recommended maximum user weight on top surface | 30 kg | |
| Net product weight | 22 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main body panels | 0.8mm thick galvanized corrugated steel | |
|---|---|---|
| External finish | Gray weather-resistant polyester powder coating | |
| Support feet | Injection-molded polypropylene with UV stabilizer | |
| Door hinges | Zinc-plated cold-rolled steel 3-knuckle butt hinges | |
| Lock mechanism | Zinc alloy keyed cam lock with 2 keys | |
| Internal shelf (optional) | 0.6mm galvanized steel with folded edge reinforcement | |
| Edge treatment | Folded hemmed steel edges, no sharp exposed cuts | |
| Frame reinforcement | 0.8mm galvanized steel internal corner bracing | |
| Fasteners | Stainless steel exterior-grade screws | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Door operation | Two full-height side-hinged doors swing outward 110 degrees for full access | |
|---|---|---|
| Locking function | Keyed cam lock secures both doors simultaneously when engaged | |
| Base elevation | Four corner feet lift cabinet above ground to prevent moisture pooling | |
| Shelf adjustability | One adjustable shelf supports 5 position increments on 100mm vertical spacing | |
| Weather sealing | Overlapping door seam and folded top lip block direct rain ingress | |
| Surface placement | Flat overhanging top supports light outdoor items such as planters or small tools | |
| Wall anchoring compatibility | Pre-drilled rear panel holes accept anti-tip anchors for securing to walls | |
| Assembly requirement | Knock-down flat pack assembly with included hex key hardware | |
| Key lock cylinder diameter | 20 mm | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential patio/garden use | Stores garden tools, pool supplies, and outdoor accessories with weather protection | |
|---|---|---|
| Balcony storage application | Compact footprint fits small apartment balconies for cleaning supply storage | |
| Commercial outdoor site use | Secures maintenance tools at building entrances, parking lots or park facilities | |
| Garage supplementary storage | Holds automotive supplies and hardware with elevated base resisting concrete moisture | |
| Target user group | Homeowners, property management teams, and small business operators needing lockable outdoor storage | |
| Recommended placement surface | Flat concrete, patio stone, or decking surface to ensure stable foot support | |
| Color option availability | 1 standard light gray finish, matching common outdoor metal furniture palettes |
EU Market Access Requirements* EN Standards
| EN 16121:2013+A1:2017 | Storage furniture for non-domestic use, safety and strength requirements | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage furniture, safety and structural performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable to dimensional and structural acceptance | |
|---|---|---|
| GB/T 1732-1993 | Paint film impact resistance test, applicable to powder coating durability verification | |
| GB/T 1771-2007 | Neutral salt spray resistance test for coatings, applicable to outdoor corrosion performance | |
| GB 28007-2011 | Safety requirements for children's furniture, applicable if used in accessible family outdoor spaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable to dimensional and structural acceptance; 2. GB/T 1732-1993: Paint film impact resistance test, applicable to powder coating durability verification; 3. GB/T 1771-2007: Neutral salt spray resistance test for coatings, applicable to outdoor corrosion performance; 4. GB 28007-2011: Safety requirements for children's furniture, applicable if used in accessible family outdoor spaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
