Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 470 x 1080 mm | |
|---|---|---|
| Top open shelf internal height | 270 mm | |
| Middle side open shelf internal height | 270 mm | |
| Lower side open shelf internal height | 270 mm | |
| Central sliding door panel dimensions | 800 x 540 mm | |
| Side open shelf column width | 200 mm | |
| Metal frame section thickness | 20 mm | |
| Internal shelf panel thickness | 18 mm | |
| Floor clearance | 0 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Per shelf static load capacity | 25 kg | |
|---|---|---|
| Sliding door track cycle rating | 20000 open/close cycles | |
| Product net weight | 45 kg | |
| Recommended maximum stored item weight per compartment | 40 kg | |
| Surface scratch resistance (metal frame) | Level 2 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer frame | 1.0mm thick cold-rolled steel with matte dark powder coating | |
|---|---|---|
| Sliding door panel | 18mm thick engineered wood with textured dark wood grain veneer | |
| Internal shelves and dividers | 18mm thick particleboard with dark matte laminate finish | |
| Back panel | 3mm thick hardboard with dark matte finish | |
| Sliding door track | 1.2mm thick galvanized steel with nylon roller glides | |
| Base trim | 1.0mm thick powder-coated steel matching frame finish | |
| Edge banding | 0.8mm thick PVC edge banding on all wood panel edges | |
| Fasteners | Zinc-plated steel cam lock and screw hardware | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Central sliding door operation | Horizontal sliding track allows door to shift fully left or right to access side storage | |
|---|---|---|
| Shelf configuration | Fixed full-width top shelf, fixed lower side shelves with open display access | |
| Door opening clearance | 0 mm outward clearance required, door slides fully within cabinet frame | |
| Anti-tip safety | Wall anchor kit included to secure cabinet to wall and prevent tipping | |
| Storage access | Open display storage on exposed side shelves, concealed storage behind sliding door | |
| Surface utilization | Flat full-width top surface supports display of decorative items or daily objects | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Home living room use | Placed against sofa wall for media accessory, book and decor storage | |
|---|---|---|
| Home office use | Positioned under window or against office wall for document and supply storage | |
| Entryway use | Used as console cabinet for entryway storage of keys, bags and seasonal items | |
| Small commercial space use | Installed in lounge areas or break rooms for shared supply storage | |
| Recommended placement | Positioned on level hard flooring with wall anchoring for stability |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic and kitchen storage furniture | |
|---|---|---|
| EN 1022:2018 | Stability testing for freestanding seating and storage furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet structural safety | |
|---|---|---|
| GB/T 24821-2009 | Performance requirements for metal furniture storage units, applicable to frame durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet structural safety; 2. GB/T 24821-2009: Performance requirements for metal furniture storage units, applicable to frame durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
