Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1680 x 460 x 810 mm | |
|---|---|---|
| Door panel height | 540 mm | |
| Upper trim panel height | 130 mm | |
| Single door width | 830 mm | |
| Corner radius | 60 mm | |
| Top surface thickness | 18 mm | |
| Metal frame profile width | 20 mm | |
| Interior shelf depth | 420 mm | |
| Adjustable shelf height positions | 5 positions | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total product weight | 46 kg | |
|---|---|---|
| Top surface static load capacity | 80 kg | |
| Hinge open/close cycle rating | 80000 cycles | |
| Door opening angle | 110 degrees | |
| Anti-tip restraint load rating | 50 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Warranty period | 2 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass core | 18mm E1 grade MDF/particleboard | |
|---|---|---|
| Door front finish | 0.6mm walnut chevron veneer over MDF substrate | |
| Top surface | 6mm dark grey sintered stone on 12mm MDF backing | |
| Outer frame | 20mm silver anodized aluminum alloy | |
| Upper front trim | 5mm black tempered glass panel | |
| Edge banding | 1mm PVC edge banding on interior carcass edges | |
| Door hinges | Cold-rolled steel soft-close concealed hinges | |
| Back panel | 3mm hardboard with melamine finish | |
| Adjustable shelves | 15mm MDF with matching woodgrain laminate | |
| Base glides | 5mm height-adjustable nylon glides | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Soft-close door mechanism | Concealed hinges with hydraulic damping to prevent slamming | |
|---|---|---|
| Adjustable interior shelving | 32mm-spaced shelf pin holes allow 5 height positions for flexible storage | |
| Dust-sealed storage | Full door seals and enclosed back panel prevent dust accumulation on stored items | |
| Floor leveling adjustment | Nylon glides adjust up to 5mm to correct uneven floor surfaces | |
| Wall anti-tip anchoring | Included steel strap secures cabinet back to wall studs for child safety | |
| Scratch-resistant top surface | Sintered stone top resists scratches, heat, and moisture for daily use | |
| Handleless door operation | Push-to-open or recessed edge pull design with no exposed external handles | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Dining room sideboard | Stores tableware, linens, and serving pieces along dining area walls | |
|---|---|---|
| Living room media storage | Holds media devices and accessories with display space on top | |
| Entryway console cabinet | Provides concealed storage for entry items and decor display | |
| Office breakroom storage | Stores kitchen supplies, dishes, and breakroom accessories | |
| Contemporary interior fit-out | Matches minimalist, modern luxury, and Italian-style interior schemes |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and kitchen storage cabinets | |
|---|---|---|
| EN 13722:2004 | Test methods for strength and durability of furniture hinges |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for cabinet structural integrity | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade ≤0.124mg/m³ requirement | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for cabinet structural integrity; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade ≤0.124mg/m³ requirement; 3. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
