Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 450 x 900 mm | |
|---|---|---|
| Raised gallery lip height | 50 mm | |
| Open display shelf compartment height | 300 mm | |
| Open shelf compartment depth | 400 mm | |
| Lower enclosed cabinet internal height | 500 mm | |
| Single cabinet door width | 580 mm | |
| Carcass side panel thickness | 25 mm | |
| Adjustable internal shelf thickness | 18 mm | |
| Door panel thickness | 20 mm | |
| Base plinth height | 50 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 70 kg | |
|---|---|---|
| Unit net weight | 85 kg | |
| Door hinge cycle rating | 80000 open/close cycles | |
| Recommended applicable users | Household, small office dining/lounge areas | |
| Product warranty period | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass frame and side panels | 18mm thick E1-grade MDF with light taupe matte lacquer finish | |
|---|---|---|
| Lower cabinet doors and top front trim | 18mm thick MDF substrate with dark walnut fluted wood veneer | |
| Top work surface | 25mm thick high-pressure dark brown laminated particleboard | |
| Internal cabinet shelves | 18mm thick E1-grade engineered wood with walnut veneer finish | |
| Door hinges | Cold-rolled steel soft-close concealed hinges with nickel plating | |
| Back panel | 5mm thick density board with dark matching finish | |
| Open shelf lighting | 3000K warm white LED strip with concealed aluminum channel | |
| Edge banding | 1mm thick PVC edge banding matched to panel finish | |
| Base plinth trim | Powder-coated light taupe aluminum alloy | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Lower cabinet storage | Three hinged doors enclose three separate storage compartments with one adjustable shelf each | |
|---|---|---|
| Door operation | Soft-close hinges allow 110-degree door opening with automatic quiet latching in final 15 degrees | |
| Display shelf lighting | Integrated warm LED strip illuminates open shelf, activated by touch-sensitive switch with 3-level dimming | |
| Shelf adjustability | Internal cabinet shelves support 50mm height adjustment via pre-drilled holes in cabinet sides | |
| Gallery top function | Raised perimeter lip prevents decorative items from sliding off the top surface | |
| Anti-tip protection | Two wall-mounted anti-tip connectors secure the cabinet to wall studs to prevent forward tipping | |
| Cable management | 1 x 60mm diameter cable grommet in open shelf back panel for charging display items | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential dining room | Placed against a wall as buffet storage for tableware, linens and decorative display items | |
|---|---|---|
| Modern living room | Positioned below wall art as display and storage for media accessories and decor | |
| Open-plan office lounge | Used as a hospitality storage unit for refreshments, corporate decor and supplies | |
| Apartment entryway | Installed in entry foyers for key, accessory and shoe storage with surface display | |
| Recommended matching furniture | Pairs with fluted walnut dining sets, taupe upholstered seating, and warm metallic accents | |
| Required installation space | Requires 1900mm clear wall width and 500mm floor depth for full door clearance | |
| Target user group | Design-focused residential and light commercial customers seeking modern light-luxury storage |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and kitchen storage furniture, applicable to structural stability | |
|---|---|---|
| EN 13986:2004+A1:2015 | Performance specifications for wood-based panels for furniture construction | |
| EN 62471:2008 | Photobiological safety for LED lighting products, applicable to integrated display strip |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural and finish quality inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for E1-grade panel acceptance | |
| GB/T 4893.4-2013 | Surface film adhesion test method for furniture finishes, applicable to lacquer and laminate surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural and finish quality inspection; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for E1-grade panel acceptance; 3. GB/T 4893.4-2013: Surface film adhesion test method for furniture finishes, applicable to lacquer and laminate surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
