PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1800 × 2000 × 260 mm
Quilted comfort layer thickness	50 mm
Side border panel height	260 mm
Edge piping trim width	8 mm
Grid tuft spacing (horizontal)	150 mm
Grid tuft spacing (vertical)	150 mm
Label patch size (side)	80 x 60 mm
Edge support reinforcement width	100 mm
Minimum bed frame slat spacing compatibility	70 mm
Side Rail Thickness	40 mm
Slat Spacing	80 mm
Center Support Leg Count	Recommended 6legs

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Product net weight	45 kg
Static weight capacity	360 kg
Recommended single sleeper weight limit	180 kg
Firmness rating	6/10 (medium-firm)
Motion transfer isolation rating	80%
Edge support static load capacity	150 kg
Full expansion time after unpacking	72 hours
Expected structural service life	10 years
Cover fabric abrasion resistance	30000 cycles
Bed Static Load Reference	400 kg

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Top sleep surface cover	Quilted grey knitted polyester fabric
Side border panel	Dark grey woven 3D mesh fabric
Edge trim	Light grey stitched polyurethane piping
Comfort top layer	20mm charcoal-infused memory foam over 30mm high-density polyfoam
Support core	Individually pocketed 1.4mm steel innerspring coils
Edge support system	High-density firm foam perimeter encasement
Bottom anti-slip layer	Non-woven polyester fabric with anti-skid dots
Internal tufting ties	High-tenacity polyester cord
Label patches	Woven synthetic fabric with printed compliance text
Slat Thickness	15 mm bent plywood or solid timber
Primary Connector Specification	Reference M8-M10 bolts with at least 2 fixing points per corner
Reference Finish / Color Count	Recommended 6timber/upholstery options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Grid tufting construction	Machine-tufted uniform square grid to lock internal layers
Breathable side ventilation	3D woven mesh border allows internal air circulation
Edge support function	Reinforced foam perimeter maintains firmness when sitting on edges
Motion isolation function	Individually pocketed coils reduce movement transfer between sleep partners
Compressed roll-pack delivery	Vacuum-sealed and rolled for easy transport to upper floors
Dual-side usability	Single-sided design with designated top sleep surface
Frame compatibility	Fits platform beds, slatted bases, box springs, and adjustable bed frames
Pressure relief function	Layered foam top distributes body weight to reduce pressure points on shoulders and hips
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2300× 900× 450 mm/carton in 4 cartons
Reference Packaged Gross Weight	130 kg/set
Reference Packaging Volume	0.9 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Primary residential use	King-size bed in master bedrooms, for two adult sleepers
Secondary residential use	Guest bedrooms for temporary or long-term visitor use
Compatible bed base types	Suitable for platform frames, slatted bases, and adjustable bed foundations
Recommended sleeper types	Back and combination sleepers requiring medium-firm spinal support
Climate suitability	Suitable for warm climates due to breathable mesh side border
Installation scenario	Suitable for small apartments and stair access without large delivery teams

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1957:2012	Applicable standard for domestic mattress functional performance and durability test methods
EN 14976:2008	Applicable standard for mattresses dimensional tolerance and structural stability requirements

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 26706-2011	Applicable standard for flexible polyurethane foam for furniture upholstery, for foam layer performance verification
GB 20400-2006	Applicable standard for leather/fabric upholstery harmful substance limits, for cover fabric compliance

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 26706-2011: Applicable standard for flexible polyurethane foam for furniture upholstery, for foam layer performance verification;
2. GB 20400-2006: Applicable standard for leather/fabric upholstery harmful substance limits, for cover fabric compliance;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · MAT-GRY-GRID-260

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · MAT-GRY-GRID-260

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · MAT-GRY-GRID-260Open Export Tool

Quick Actions

Post an RFQ

Product Description

This unbranded grey grid-tufted medium profile hybrid innerspring mattress, model MAT-GRY-GRID-260, presents a streamlined, cohesive visual defined by uniform square grid tufting across its top sleep surface, finished with light grey stitched polyurethane piping along all edges. The top cover uses soft quilted grey knitted polyester, paired with dark grey woven 3D mesh side borders, creating a subtle two-tone neutral aesthetic that blends seamlessly with most bed frame finishes. Its construction layers material performance for balanced comfort and durability. The 50mm quilted comfort top combines charcoal-infused memory foam over high-density polyfoam, secured to the support core by high-tenacity polyester cord tufting that prevents internal layer shift over time. The support core uses individually pocketed steel innerspring coils, surrounded by a high-density firm foam perimeter encasement for edge reinforcement. A non-woven polyester anti-slip layer with anti-skid dots forms the bottom, while the piped edge trim adds tailored structural finish. Key functional benefits support consistent sleep quality. Individually pocketed coils deliver effective motion isolation to reduce disturbance between sleep partners, while the reinforced foam perimeter maintains stable firmness for sitting or resting near mattress edges. The 3D woven mesh side border enables steady internal air circulation to support breathability, ideal for warmer climate use. Delivered vacuum-sealed and roll-packed, it can be easily transported to upper floors or small apartment spaces without large delivery crews, and requires full expansion over 72 hours after unpacking. Note that this is a single-sided design with a designated top sleep surface, and fits platform beds, slatted bases, box springs, and adjustable bed frames. For residential settings, it is sized as a King option ideal for master bedrooms accommodating two adult sleepers, particularly back and combination sleepers seeking medium-firm spinal support, and also works well for guest bedrooms serving both temporary and long-term visitors. Procurement teams and residential buyers should note the product ships across multiple cartons, with a reference assembly time per set, and plan to account for the 72-hour expansion window before first use. The static weight capacity supports shared adult use, with defined edge load capacity for stable seated use, making it a practical choice for everyday residential deployment.

Grey Grid-Tufted Medium Profile Hybrid Innerspring Mattress Specifications
