Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1800 × 2000 × 230 mm | |
|---|---|---|
| Quilted cover tuft indent depth | 8 mm | |
| Comfort layer total thickness | 60 mm | |
| Support core (pocket spring) thickness | 150 mm | |
| Bottom base support foam thickness | 20 mm | |
| Perimeter edge support width | 70 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended maximum static load capacity | 400 kg | |
|---|---|---|
| Single-side usable design static point load | 120 kg | |
| Firmness rating | 6 (medium-firm) | |
| Fabric air permeability | 85 mm/s | |
| Spring count (king size) | 1080 coils | |
| Product net weight (king size) | 55 kg | |
| Motion transfer isolation rate | 92% | |
| Warranty period | 5 years | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top sleep surface cover | Cashmere-blend knitted fabric, 280g/sqm weight, quilted texture | |
|---|---|---|
| Upper comfort padding | 100% natural cotton wadding, 20mm thickness, soft skin-friendly layer | |
| Support layer fill options | 40mm high-density memory foam / 3E coconut coir / natural latex | |
| Core support unit | 9-zone individually encased pocket springs, 2.0mm steel wire diameter, heat-tempered | |
| Perimeter edge support | High-density polyurethane foam, 40kg/m³ density, reinforced border | |
| Bottom base layer | 20mm high-resilience support foam, 35kg/m³ density, non-slip finish | |
| Internal isolation fabric | Non-woven polypropylene fabric, separates spring and comfort layers | |
| Quilted cover inner lining | 25g/sqm anti-dust mite treated non-woven fabric | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| 9-zone spinal support zoning | Variable spring coil tension across head, shoulder, lumbar, hip, leg, foot zones for targeted pressure relief | |
|---|---|---|
| Independent pocket spring motion isolation | Coils operate independently to reduce partner disturbance from movement during sleep | |
| Breathable surface air circulation | Dimpled tufted surface and porous knit cover promote airflow to reduce heat buildup | |
| Edge support reinforced seating | Perimeter high-density foam prevents edge sag when sitting on mattress sides | |
| Variant fill customization | Available in memory foam, coconut coir, latex, breathable foam fill configurations to match firmness preferences | |
| Compression roll packaging compatibility | Vacuum compressed for shipping without damaging spring core or foam layers | |
| Standard bed frame compatibility | Fits standard platform beds, slatted frames, box springs, and adjustable bed bases | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential bedroom use | Suitable for master bedrooms, guest rooms, and youth rooms across standard bed sizes | |
|---|---|---|
| Hotel and hospitality furnishing | Ideal for budget to mid-tier hotel rooms with 9-zone support and durable hybrid construction | |
| Rental property furnishing | Cost-effective hybrid build suits long-term rental apartment and dormitory furnishing | |
| Adjustable bed base compatibility | Flexible foam and pocket spring construction works with electric adjustable bed frames | |
| Spinal alignment for adult users | Medium-firm 9-zone design supports natural spinal posture for back and side sleepers |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Mattress durability test standard | EN 1957:2012 | |
|---|---|---|
| Domestic bedding fire safety standard | EN 597:2015 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Mattress dimensional tolerance standard | GB/T 26706 | |
|---|---|---|
| Textile safety standard for bedding | GB 18401Class B |
This product must meet the following technical requirements: 1. Mattress dimensional tolerance standard: GB/T 26706; 2. Textile safety standard for bedding: GB 18401Class B; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
