Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1800 × 2000 × 300 mm | |
|---|---|---|
| Pillow-top comfort layer thickness | 50 mm | |
| Pocket spring core height | 190 mm | |
| Quilted top panel thickness | 10 mm | |
| Side border height | 300 mm | |
| Vent/tuft indentation spacing | 150 mm | |
| Edge support foam width | 70 mm | |
| Corner radius | 30 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 49 kg | |
|---|---|---|
| Static weight capacity | 227 kg | |
| Pocket spring coil count | 660 | |
| Spring wire diameter | 2.4 mm | |
| Quilted foam density | 25 kg/m³ | |
| Support foam density | 30 kg/m³ | |
| Memory foam layer density | 60 kg/m³ | |
| Rolling durability cycle rating | 50000 cycles | |
| Edge static load rating | 113 kg | |
| Full expansion time after unpacking | 72 hours |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top cover fabric | Beige stretch polyester knit, quilted construction | |
|---|---|---|
| Side border fabric | Textured woven polyester fabric, stitched reinforced seams | |
| Top tufted/vented panel | Quilted polyester wadding and soft foam pad | |
| Pillow-top comfort layer | Multi-layer polyurethane soft foam and wave foam | |
| Spring core | Individually wrapped tempered steel pocket coils | |
| Edge support | High-density polyurethane foam encasement | |
| Identification labels | Woven fabric tags sewn to side border | |
| Stitching seam pitch | 25 mm | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Motion isolation | Individually pocketed coils limit cross-surface movement transfer | |
|---|---|---|
| Breathability | Vented recesses across top panel and porous knit cover improve air circulation | |
| Edge support | Reinforced foam perimeter prevents edge sag when sitting near mattress sides | |
| Compressed packaging compatibility | Vacuum compressed for reduced shipping volume prior to unpacking | |
| Surface firmness | Medium plush comfort level from layered foam and spring support | |
| Cleaning suitability | Spot-clean only fabric cover to prevent damage to quilted layers | |
| Noise reduction | Individually wrapped coils minimize spring squeak during position changes | |
| Zoned support | 5 comfort zones align with body pressure points for spinal alignment | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential bedroom use | Fits standard queen-size bed frames for master or guest bedrooms | |
|---|---|---|
| Hotel guest room use | Meets mid-tier hotel bedding durability and comfort requirements | |
| Adjustable bed base compatibility | Flexible pocket spring construction works with powered adjustable bed frames | |
| All sleeper position suitability | Zoned medium-plush support works for side, back, and stomach sleepers | |
| Platform bed frame use | Works directly on slatted platform beds without separate box spring | |
| Commercial hospitality furnishing | Suitable for serviced apartment and short-term rental furnishing projects |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Domestic bedding flammability standard | EN 597:2015 | |
|---|---|---|
| Furniture durability test standard | EN 1957:2012 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Contract mattress durability standard | ANSI/BIFMA X2021 | |
|---|---|---|
| Furniture load test standard | ANSI/BIFMA X2017 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Mattress flammability standard | GB 20400 | |
|---|---|---|
| Spring mattress durability standard | GB/T 26706 | |
| Formaldehyde emission limit | GB 18587 |
This product must meet the following technical requirements: 1. Mattress flammability standard: GB 20400; 2. Spring mattress durability standard: GB/T 26706; 3. Formaldehyde emission limit: GB 18587; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
