PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1500 × 2000 × 100 mm | |
|---|---|---|
| Perimeter border width | 70 mm | |
| Horizontal quilt channel width | 45 mm | |
| Diamond quilt side panel height | 90 mm | |
| Label tag size | 40 x 60 mm | |
| Recommended bed frame slat spacing | 70 mm | |
| Corner radius | 20 mm | |
| Thickness tolerance | 10 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total net weight | 12 kg | |
|---|---|---|
| Static load capacity | 300 kg | |
| Firmness rating | Medium firm | |
| Foam layer density | 30 kg/m³ | |
| Rebound rate | 95% | |
| Air permeability | 3800 ml/m²·h | |
| Compression durability cycles | 80000 cycles | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top cover fabric | Grey polyester knit fabric, 220 gsm | |
|---|---|---|
| Side panel fabric | Grey polyester woven fabric, diamond quilted | |
| Quilt wadding | 4000# polyester fiber wadding | |
| Core fill | High-density 400 gsm 3D polyester fiber | |
| Bottom base layer | Anti-slip polyester mesh fabric | |
| Stitching thread | High-tenacity polyester thread, 3 stitches per cm | |
| Edge binding | Reinforced woven polyester binding | |
| Tag material | Woven polyester label with printed identification | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Installation compatibility | Fits standard platform beds, tatami frames and bunk beds | |
|---|---|---|
| Core breathability | Ventilated 3D fiber core allows full air circulation | |
| Anti-slip base | Mesh bottom prevents shifting on slatted or solid platform surfaces | |
| Quilted surface | Horizontal channel quilting secures fill to prevent shifting | |
| Packaging form | Vacuum roll-packed for transport and delivery | |
| Unpacking recovery time | 72 hours | |
| Rotation requirement | Rotate 180 degrees every 3 months | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home bedroom use | Suitable for platform beds, tatami rooms and low-profile bed frames | |
|---|---|---|
| Small apartment spaces | Ideal for compact bedrooms, loft beds and bunk beds | |
| Guest room application | Suitable for occasional guest use on foldable bed frames | |
| Student dormitory use | Fits standard single or double dormitory bed frames | |
| Rental property furnishing | Cost-effective durable option for furnished rental units | |
| Children's bedroom use | Low height reduces fall risk for young children |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 597-1:2015 | Furniture, mattress and bed base ignitability test, smouldering cigarette | |
|---|---|---|
| EN 1957:2012 | Mattresses and bed bases functional test methods and requirements |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge and public seating furniture standard, applicable for mattress support use | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, material content and emission reference |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB 20400-2006 | Leather and fur material safety limit, applicable for fabric chemical testing | |
|---|---|---|
| GB/T 26706-2011 | Furniture mattress general technical specification, applicable for performance testing | |
| GB 18401-2010 | National general safety technical code for textile products, Class B |
Standardized tender description text
This product must meet the following technical requirements: 1. GB 20400-2006: Leather and fur material safety limit, applicable for fabric chemical testing; 2. GB/T 26706-2011: Furniture mattress general technical specification, applicable for performance testing; 3. GB 18401-2010: National general safety technical code for textile products, Class B; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
