Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 400 x 1200 mm | |
|---|---|---|
| Leg height | 120 mm | |
| Upper drawer front height | 180 mm | |
| Glass door zone height | 900 mm | |
| Internal shelf depth | 360 mm | |
| Single glass panel size | 380 x 220 mm | |
| Individual drawer internal width | 410 mm | |
| Drawers internal depth | 340 mm | |
| Floor clearance under base | 100 mm | |
| Top surface usable area | 860 x 360 mm | |
| Adjustable shelf spacing range | 280 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 40 kg | |
|---|---|---|
| Net weight | 25 kg | |
| Recommended maximum total loaded weight | 120 kg | |
| Hinge open-close cycle rating | 50000 cycles | |
| Drawer slide open-close cycle rating | 30000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main frame construction | 18mm thick solid rubberwood with natural clear matte finish | |
|---|---|---|
| Door panels | 5mm thick semi-transparent frosted tempered glass set in 20mm wood frames | |
| Internal shelves | 15mm thick engineered wood with matching wood veneer finish | |
| Drawer boxes | 12mm thick plywood with dovetail joint construction | |
| Support legs | 40 x 40mm solid square wood legs, level floor contact | |
| Edge banding | 1mm thick matching wood veneer edge banding on all exposed panel edges | |
| Back panel | 3mm thick hardboard with wood grain finish | |
| Door hardware | Zinc alloy concealed hinges with matte black finish | |
| Drawer slides | Side-mount cold-rolled steel 3/4 extension slides | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Upper drawer operation | Two equal-width pull-out drawers with integrated recessed finger pulls, no external handles | |
|---|---|---|
| Lower door operation | Double hinged glass doors with single central integrated vertical recessed pull, opens outward to 110 degrees | |
| Internal shelf adjustment | Three adjustable shelves with 5 position height options on metal shelf pins | |
| Display function | Semi-transparent glass panels obscure stored items while allowing partial visibility for curated display | |
| Surface display function | Flat solid top surface supports decorative items, table lamps or small plant displays | |
| Anti-tip safety | Included wall anchor anti-tip connector secures cabinet to wall to prevent tip-over | |
| Leveling adjustment | Included plastic foot glides on leg bases allow minor adjustment for uneven floors | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room accent storage | Suitable for placement against living room walls for display of decor and storage of household items | |
|---|---|---|
| Dining room side storage | Usable as dining room storage for tableware, linens and serving pieces | |
| Entryway organizer | Fits in residential entryways for storage of keys, mail, shoes and entry accessories | |
| Bedroom linen storage | Appropriate for bedroom use to store linens, clothing and personal items | |
| Home office document storage | Suitable for home offices to store books, files and office supplies | |
| Recommended wall placement | Place against solid interior walls with attached anti-tip anchor for safe use |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - safety requirements and test methods | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety for domestic storage furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for internal engineered wood components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wood furniture; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable for internal engineered wood components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
