Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1500 x 800 x 600 mm | |
|---|---|---|
| Sintered stone tabletop thickness | 20 mm | |
| Frame square tube wall thickness | 1.5 mm | |
| Integrated tea tray serving area size | 800 x 450 mm | |
| Tea boiler cutout dimensions | 370 x 200 mm | |
| Lower open storage shelf clearance height | 280 mm | |
| Leg footprint outer dimension | 1440 x 740 mm | |
| Cross-brace height from floor | 120 mm | |
| Table edge overhang beyond frame | 30 mm | |
| Lower shelf panel thickness | 12 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 80 kg | |
|---|---|---|
| Integrated tea boiler power rating | 1500 W | |
| Recommended serving capacity | 6 people | |
| Sintered stone surface heat resistance | 1200 °C | |
| Sintered stone surface abrasion resistance | 6000 revolutions | |
| Product net weight | 48 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | Dark veined grade AAA sintered stone, polished finish | |
|---|---|---|
| Support frame | Black powder-coated welded square steel tube | |
| Lower storage shelf | Black matte laminated tempered glass panel | |
| Tea tray drainage area | Integrated grooved sintered stone surface with hidden drain outlet | |
| Boiler mounting plate | 1.2mm thick black cold-rolled steel with heat-resistant coating | |
| Frame weld points | Ground and powder-coated smooth finish | |
| Edge banding | Matched black epoxy edge sealing for sintered stone cut edges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Integrated electric tea boiler | Automatic bottom water feed, boil and sterilize functions, stainless steel kettle and pot | |
|---|---|---|
| Tea tray drainage system | Hidden drain outlet under grooved serving area for wastewater collection | |
| Lower open storage shelf | Full-width flat surface for storing tea accessories, cups or storage boxes | |
| Frame stability bracing | Horizontal cross bars at floor level connecting all four legs to prevent wobble | |
| Leveling foot pads | 4 adjustable non-slip nylon foot pads at leg bases for uneven floors | |
| Surface anti-stain performance | Non-porous sintered stone surface resists tea stains and requires only wiping cleaning | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Office reception area | Placed in front of reception sofas to serve tea to visiting guests, low height matches sofa seating | |
|---|---|---|
| Home living room | Positioned in front of sectional sofas for daily family tea drinking and casual refreshment | |
| Private tea room | Used as a compact dedicated tea service station for small group gongfu tea sessions | |
| Lounge waiting area | Installed in business lounges to provide self-serve tea and refreshment for waiting visitors | |
| Recommended accessory pairing | Pair with low-profile floor cushions or 350mm seat height tea stools for seated service |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety requirements for domestic tables | |
|---|---|---|
| EN 13832:2003 | Furniture - Test methods for table surfaces, applicable for surface resistance testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden and composite furniture, applicable for shelf panel quality | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable if shelf uses composite wood panel | |
| GB 4706.19-2008 | Safety requirements for liquid heating household appliances, applicable for integrated boiler |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden and composite furniture, applicable for shelf panel quality; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable if shelf uses composite wood panel; 3. GB 4706.19-2008: Safety requirements for liquid heating household appliances, applicable for integrated boiler; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
