Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 600 x 600 x 460 mm | |
|---|---|---|
| Table top thickness | 50 mm | |
| Decorative panel leg cross section | 120 x 120 mm | |
| Lower shelf clearance from floor | 120 mm | |
| Lower shelf usable depth | 480 mm | |
| Lower shelf usable width | 480 mm | |
| Undertop clearance between top and lower shelf | 260 mm | |
| Table edge overhang beyond leg | 40 mm | |
| Decorative molded plinth base height | 60 mm | |
| Embedded control button strip length | 120 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Table top static distributed load | 150 kg | |
|---|---|---|
| Lower shelf static distributed load | 50 kg | |
| Electric lift maximum load capacity | 80 kg | |
| Paint film hardness | 2H | |
| Wood moisture content | 12% | |
| Lift system design lifespan | 10 years | |
| Formaldehyde emission level | 0.05 mg/m³ | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Core panel substrate | 18mm thick E1 grade medium density fiberboard | |
|---|---|---|
| Surface veneer | 0.6mm thick natural red mahogany wood veneer | |
| Edge banding | 0.6mm thick solid wood veneer edge trim | |
| Surface finish | 0.5mm thick high-gloss water-based paint applied with 5-base-3-top coat process | |
| Structural hardware | Zinc-plated steel cam lock and dowel connectors | |
| Lift mechanism components | Powder-coated steel linear drive columns and silicone control buttons |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated electric height adjustment | Embedded silicone button controls adjust table height via linear drives | |
|---|---|---|
| Open lower storage shelf | Fixed open shelf provides auxiliary storage for publications or table items | |
| Anti-collision lift protection | Drive system automatically retracts upon encountering obstacles during adjustment | |
| Leveling foot adjustment | Base feet include adjustable glides to compensate for uneven floor surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office reception areas | Matches formal red mahogany executive desk suites for visitor seating areas | |
|---|---|---|
| Office lounge and waiting zones | Compact square footprint fits between sofas for tea and document placement |
EU Market Access Requirements* EN Standards
| EN 15372:2008+A2:2016 | Furniture – Strength, durability and safety requirements for non-domestic tables | |
|---|---|---|
| EN 12521:2015 | Furniture – Strength, durability and safety requirements for domestic tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products, applicable to load and durability testing for height-adjustable tables |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural tolerance | |
|---|---|---|
| GB 18584-2001 | Limits of harmful substances in wood furniture for interior decoration materials | |
| GB/T 4893.4-2013 | Test for surface wear resistance of furniture coatings |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural tolerance; 2. GB 18584-2001: Limits of harmful substances in wood furniture for interior decoration materials; 3. GB/T 4893.4-2013: Test for surface wear resistance of furniture coatings; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
