Chinese Style Solid Wood Automatic Mahjong Dining Table (model AMT-CN-RW-04) is listed under Traditional Coffee Table, with overall dimensions of 1040 × 1040 × 810 mm and main material of MDF. Load capacity: 150 kg. Certifications: Traditional,Chinese,style,carved,open,apron,dual,dining/mahjong,function,4-player,square,layout. This page consolidates 6 groups of specifications and GB / EN standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1040 x 1040 x 810 mm | |
|---|---|---|
| Tabletop thickness | 45 mm | |
| Square leg section size | 80 x 80 mm | |
| Knee clearance height under apron | 660 mm | |
| Apron height between leg top and knee opening | 105 mm | |
| Central mahjong playing surface size | 850 x 850 mm | |
| Dining conversion cover size | 1040 x 1040 mm | |
| Open apron decorative cutout width | 220 mm | |
| Control strip length on front apron | 280 mm | |
| Leg base footprint spread | 960 x 960 mm | |
| Under-table floor to mechanism clearance | 630 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Static distributed tabletop load capacity | 150 kg | |
|---|---|---|
| Product net weight | 80 kg | |
| Seating capacity | 4 persons | |
| Shuffling mechanism noise rating | 60 dB | |
| Compatible mahjong tile size | 42 mm | |
| Included mahjong tile sets | 2 sets of 144 tiles | |
| Power supply rating | 220V/50Hz | |
| Surface finish abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer table frame and legs | Solid rosewood-toned hardwood with reddish lacquer finish | |
|---|---|---|
| Internal mechanism support frame | Powder-coated high-carbon steel | |
| Apron decorative carvings | Matching solid hardwood with openwork curved detailing | |
| Tabletop playing surface insert | Wear-resistant flocked fabric over shuffler base | |
| Dining conversion cover panel | Matching solid hardwood panel with flush fit | |
| Control panel buttons | ABS plastic with labeled function keys |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Automatic shuffling mechanism | Dual-motor silent shuffling system with 4-port tile delivery | |
|---|---|---|
| Dual-use conversion | Removable solid wood cover converts game table to standard dining surface | |
| Front edge control panel | Embedded button strip for shuffle, lift, dice, and mode selection | |
| Tile lifting function | Motorized tile riser elevates pre-stacked tiles to tabletop level |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home game and dining space | Suited for private dining rooms or living areas requiring dual dining/mahjong use | |
|---|---|---|
| Private club and lounge areas | Appropriate for boutique mahjong rooms and member lounge seating areas |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic dining tables | |
|---|---|---|
| EN 60335-1:2012 | Safety standard for household electrical appliances, applicable to mechanism |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to solid wood table frame | |
|---|---|---|
| GB 4706.1-2005 | Safety requirements for household electrical appliances, applicable to electric shuffler |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to solid wood table frame; 2. GB 4706.1-2005: Safety requirements for household electrical appliances, applicable to electric shuffler; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
