Red Brown Wood Veneer Convertible Dining Height Automatic Mahjong Table (model AMT-RW4L-1040) is listed under Traditional Coffee Table, with overall dimensions of 1040 × 1040 × 800 mm and main material of MDF. Load capacity: 150 kg. Certifications: Chinese,style,4-seat,convertible,dining/game,use,wood,finish. This page consolidates 6 groups of specifications and GB / EN standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall table dimensions | 1040 x 1040 x 800 mm | |
|---|---|---|
| Internal play area dimensions | 830 x 830 mm | |
| Under-table knee clearance height | 630 mm | |
| Leg cross-section dimension | 160 x 160 mm | |
| Apron height below table top | 120 mm | |
| Table top edge overhang | 30 mm | |
| Control button diameter | 20 mm | |
| Leg base groove height | 80 mm | |
| Tile lift opening stroke | 120 mm | |
| Power cord length | 2400 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Table net weight | 141 kg | |
|---|---|---|
| Table top static load capacity | 150 kg | |
| Suitable tile size range | 48 mm | |
| Seating capacity | 4 persons | |
| Shuffling operating noise | 65 dB | |
| Tile delivery cycle time | 3 seconds | |
| Recommended user weight per seat | 120 kg | |
| Warranty period | 12 months | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Table frame and apron | E1 grade engineered wood with red brown wood veneer finish | |
|---|---|---|
| Support legs | Solid rubber wood block construction with routed groove detailing | |
| Table top core | 18mm high-density particleboard substrate with wear-resistant laminate surface | |
| Automatic mechanism housing | 1.2mm cold-rolled steel frame with anti-corrosion powder coating | |
| Included mahjong tiles | Melamine imitated jade magnetic tiles, 2 full sets of 144 tiles | |
| Dining conversion cover | 8mm tempered glass or matching wood veneer hard cover |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Automatic shuffling and tile feeding | Rotor-style direct-drive mechanism, one-button start, anti-jam tile detection | |
|---|---|---|
| Electronic dice control | Dual-mode LED dice rolling integrated with front edge control panel | |
| Convertible dual use | Included flat cover converts table to standard dining surface when not playing mahjong | |
| Multi-game compatibility | Mechanism supports standard 4-player Chinese mahjong rule sets |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential game room | Suitable for home entertainment spaces with matching wood furniture decor | |
|---|---|---|
| Private club lounge | Appropriate for small member club mahjong rooms requiring dining function |
EU Market Access Requirements* EN Standards
| Furniture stability | EN 15372:2016 Domestic tables strength and durability | |
|---|---|---|
| Electromagnetic compatibility | EN 55014:2021 Household appliance EMC emission |
Standards applicable to China-market projects
| Formaldehyde emission | GB/T 39600E1 grade | |
|---|---|---|
| Furniture mechanical safety | GB/T 10357.1Table static load test | |
| Electrical safety | GB 4706.1Household electrical appliance safety |
This product must meet the following technical requirements: 1. Formaldehyde emission: GB/T 39600E1 grade; 2. Furniture mechanical safety: GB/T 10357.1Table static load test; 3. Electrical safety: GB 4706.1Household electrical appliance safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
