Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall desk dimensions | 1830 x 900 x 760 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Left pedestal width | 450 mm | |
| Right cabinet pedestal width | 450 mm | |
| Central knee clearance width | 620 mm | |
| Knee clearance height | 640 mm | |
| Knee clearance depth | 550 mm | |
| Inset writing pad dimensions | 800 x 400 mm | |
| Cable grommet diameter | 60 mm | |
| Drawer internal height (per box drawer) | 120 mm | |
| Right cabinet internal height | 600 mm | |
| Edge banding thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Right cabinet shelf static load | 25 kg | |
| Recommended maximum user weight compatibility | 136 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Hinge cycle rating for cabinet door | 80000 open/close cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate | High-density fiberboard core | |
|---|---|---|
| Desktop surface | 0.6 mm red wood veneer with multi-coat polyurethane lacquer | |
| Writing pad | Inset black faux leather/vinyl surface | |
| Hardware pulls | Polished chrome-plated zinc alloy handles | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Cabinet hinges | Cold-rolled steel self-closing hinges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Left pedestal with 3 stacked drawers, right pedestal with single-door enclosed cabinet | |
|---|---|---|
| Cable management | Two circular desktop cable grommets positioned adjacent to writing pad | |
| Leveling adjustment | Integrated floor leveler feet at pedestal bases | |
| Locking security | Keyed lock on top left drawer secures all left pedestal drawers |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Fits individual manager/executive workspaces, provides dedicated work surface and storage | |
|---|---|---|
| Traditional wood-finish office environments | Matches classic red wood office furniture sets for government or corporate settings |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - work tables and desks, safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Office furniture - storage units, structural strength and durability requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products, standard for performance and durability testing for office desks |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to substrate material performance | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural quality; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to substrate material performance; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
