Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 1400 x 700 x 760 mm | |
|---|---|---|
| desktop thickness | 25 mm | |
| edge band thickness | 2 mm | |
| knee well width | 600 mm | |
| knee well clearance height | 620 mm | |
| toe kick height | 100 mm | |
| inset writing pad dimensions | 600 x 300 mm | |
| cable grommet diameter | 60 mm | |
| left cabinet internal usable width | 350 mm | |
| right drawer bank internal width | 350 mm | |
| keyboard tray dimensions | 550 x 300 mm | |
| drawer internal usable depth | 480 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| desktop static uniform load capacity | 100 kg | |
|---|---|---|
| net product weight | 85 kg | |
| drawer slide cycle rating | 50000 open/close cycles | |
| surface abrasion resistance | 2000 cycles | |
| recommended user weight capacity | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| desktop core | 18mm high-density fiberboard with 25mm total build-up | |
|---|---|---|
| desktop surface | Red-brown cherry-toned wood veneer with clear polyurethane topcoat | |
| inset writing pad | Black matte faux leather with stitched edge | |
| drawer slides | Cold-rolled steel full-extension ball bearing slides | |
| pedestal panels | 16mm engineered wood with matching veneer finish | |
| cable grommets | ABS plastic round dual grommets, white finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| storage configuration | Left full-height cabinet door, right three stacked lockable drawers | |
|---|---|---|
| cable management | Two surface-mounted grommets routing cables to under-desk space | |
| keyboard access | Pull-out sliding tray mounted under front desktop edge | |
| lock mechanism | Central key lock securing all three right-side drawers |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| private executive office | Fits single user for daily management, document processing and computer work | |
|---|---|---|
| staff workstation | Suitable for senior staff requiring integrated lockable storage at seat |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for structural verification | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and mechanical performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for desk structural stability | |
|---|---|---|
| GB/T 3327-2016 | Performance test standards for office desks, applicable for load and durability testing | |
| GB 18584-2001 | Indoor decoration material limit of formaldehyde emission for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for desk structural stability; 2. GB/T 3327-2016: Performance test standards for office desks, applicable for load and durability testing; 3. GB 18584-2001: Indoor decoration material limit of formaldehyde emission for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
