Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1600 x 760 x 760 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Left storage pedestal dimensions | 420 x 550 x 630 mm | |
| Right storage pedestal dimensions | 420 x 550 x 630 mm | |
| Central knee clearance width | 760 mm | |
| Central knee clearance height | 620 mm | |
| Central knee clearance depth | 480 mm | |
| Cable grommet diameter | 60 mm | |
| Individual drawer front dimensions | 340 x 150 mm | |
| Right cabinet interior dimensions | 380 x 500 x 580 mm | |
| Drawer pull length | 120 mm | |
| Pedestal panel thickness | 18 mm | |
| Desktop overhang | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 100 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Net product weight | 120 kg | |
| Recommended user weight capacity | 150 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate | 18mm MDF core with 0.6mm red wood veneer, high-gloss polyurethane topcoat | |
|---|---|---|
| Edge banding | 2mm thick impact-resistant PVC, matched red wood grain finish | |
| Pedestal panels | 16mm particleboard substrate with matching red wood grain melamine laminate | |
| Hardware pulls and locks | Polished chrome plated zinc alloy, drawer lock on top left drawer | |
| Drawer slides | Cold-rolled steel full-extension ball-bearing slides | |
| Leveling glides | Nylon base with steel threaded stem, adjustable height 10mm |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Storage configuration | Three stacked left drawers plus right side CPU storage compartment with door | |
|---|---|---|
| Cable management | One round desktop cable grommet for routing monitor and device power cords | |
| Drawer locking | Integrated key lock secures all three left pedestal drawers for document security | |
| Floor leveling | Adjustable base glides compensate for uneven floor surfaces to stabilize the desk |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private executive office | Fits senior management private offices with formal traditional aesthetic | |
|---|---|---|
| Traditional style government or corporate workspace | Matches formal solid wood style interiors for institutional office environments |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements for commercial workspace furniture | |
|---|---|---|
| EN 13722:2004 | Furniture strength and durability requirements for storage units integrated into desks |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for structural performance, durability and safety testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural safety and finish quality | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to pedestal panel substrate performance requirements | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural safety and finish quality; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to pedestal panel substrate performance requirements; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
