Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 2400 x 1100 x 760 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| Solid wood edge band thickness | 8 mm | |
| Central seated knee clearance height | 580 mm | |
| Central seated knee clearance width (open-well variant) | 520 mm | |
| Left pedestal drawer internal height | 150 mm | |
| Recessed writing inlay dimensions | 1200 x 400 mm | |
| Cable grommet diameter | 60 mm | |
| Plinth base height | 80 mm | |
| Keyboard tray extension travel (open variant) | 300 mm | |
| Right side cabinet internal storage height | 600 mm | |
| Desktop rounded edge radius | 20 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static uniform load capacity | 120 kg | |
|---|---|---|
| Single drawer slide load rating | 35 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Hinge open/close cycle durability | 80000 cycles | |
| Paint surface pencil hardness | 2H | |
| Paint film adhesion grade | Grade 1 | |
| Wood component moisture content | 12% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate | E1 grade high-density MDF | |
|---|---|---|
| Desktop facing | 0.6mm thick natural mahogany wood veneer | |
| Desktop coating | Matte water-based PU wood paint | |
| Central writing inlay | Black bonded leatherette | |
| Desk edge trim | Solid wood edge banding | |
| Hardware components | Zinc alloy bow pulls, steel ball-bearing slides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Two dual-side desktop grommets with internal cable tray | |
|---|---|---|
| Storage configuration | 3 left side utility drawers + 1 right side storage cabinet (open variant) | |
| Closed variant modesty panel | Full-height front modesty panel conceals under-desk area | |
| Leveling adjustment | Nylon adjustable glides at plinth base |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | For director/manager level workstations, provides storage and professional formal aesthetics | |
|---|---|---|
| Government/institutional office | Matches formal traditional office furnishing standards for administrative spaces |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for strength and durability of storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance test standard |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2003 | Performance requirements for particleboard used in furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 3. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
