Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 1400 x 700 x 760 mm | |
|---|---|---|
| desktop thickness | 29 mm | |
| knee clearance height | 660 mm | |
| knee opening width | 870 mm | |
| cable grommet diameter | 60 mm | |
| edge band thickness | 3 mm | |
| left pedestal width | 450 mm | |
| right cabinet pedestal width | 400 mm | |
| small drawer internal height | 150 mm | |
| pedestal plinth height | 100 mm | |
| desktop overhang front | 20 mm | |
| storage door internal depth | 640 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| desktop static evenly distributed load | 136 kg | |
|---|---|---|
| box drawer maximum static load | 20 kg | |
| file drawer maximum static load | 30 kg | |
| drawer slide cycle rating | 50000 cycles | |
| hinge cycle rating | 100000 cycles | |
| product net weight | 90 kg | |
| leveling foot adjustment range | 15 mm | |
| cable tray load capacity | 5 kg | |
| manufacturer warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| desktop core | E1 grade particleboard substrate | |
|---|---|---|
| desktop surface | Thermally fused reddish walnut grain melamine laminate | |
| edge trim | 3mm thick matching PVC bullnose edge banding | |
| pedestal panels | 18mm thick melamine-clad engineered wood | |
| drawer hardware | Polished chrome plated steel pull handles | |
| drawer slides | Full extension cold-rolled steel ball-bearing slides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| drawer locking system | Central keyed lock securing all 3 left drawers | |
|---|---|---|
| cable management | 60mm diameter desktop grommet for power/data routing | |
| drawer operation | Full extension pull-out access for all storage compartments | |
| leveling adjustment | Base foot glides adjust to compensate for uneven floor surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| private staff office workstation | Standard work surface size for single-user daily administrative tasks | |
|---|---|---|
| small business reception office | Formal reddish wood finish suits professional front office environments |
EU Market Access Requirements* EN Standards
| EN 527-2:2016 | Safety strength and durability requirements for office work desks | |
|---|---|---|
| EN 1335-2:2009 | Office furniture safety requirements for work surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for office desks and tables | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Sustainability standard for office furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 3327-2017 | Performance test methods for office desks | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 3327-2017: Performance test methods for office desks; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
