Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1600 x 1200 x 760 mm | |
|---|---|---|
| Desktop thickness | 40 mm | |
| Desktop edge banding thickness | 8 mm | |
| Left storage pedestal dimensions | 400 x 580 x 645 mm | |
| Right 3-drawer pedestal dimensions | 400 x 580 x 645 mm | |
| Central knee clearance width | 800 mm | |
| Knee clearance height under desktop | 645 mm | |
| Toe kick cutout height | 115 mm | |
| Pull-out keyboard tray dimensions | 600 x 415 x 650 mm | |
| Cable management grommet diameter | 76 mm | |
| Single inset writing pad dimensions | 600 x 400 mm | |
| Single drawer internal dimensions | 360 x 500 x 150 mm | |
| Left pedestal open cubby dimensions | 350 x 500 x 450 mm | |
| Side panel thickness | 25 mm | |
| Base panel thickness | 18 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 113 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Finish surface hardness | 2H | |
| Net weight of desk unit | 70 kg | |
| Recommended maximum user capacity | 2 users | |
| Formaldehyde emission level | 0.05 mg/m³ | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Panel core material | E1 grade multi-layer engineered wood | |
|---|---|---|
| Surface finish | 0.6mm reddish-brown natural wood veneer with water-based lacquer | |
| Edge treatment | 8mm solid wood edge banding, rounded profile | |
| Drawer slides | Cold-rolled steel 3-section full-extension ball-bearing slides, quiet operation | |
| Hardware pulls and locks | Zinc alloy drawer pulls, brass-core key lock for top right drawer | |
| Inset writing pads | 10mm thick black wear-resistant leatherette writing surface |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Four desktop grommets route cables to under-desk space | |
|---|---|---|
| Keyboard storage | Center-mounted pull-out keyboard tray slides out for typing, retracts flush when not in use | |
| Storage security | Top drawer on right pedestal includes key lock to secure valuables | |
| Left pedestal storage | Hinged door cabinet plus open vertical cubby for CPU, files or office supplies |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office use | Suitable for face-to-face two-person workstations in general office areas | |
|---|---|---|
| Small business administrative space | Ideal for shared admin or staff work areas with limited floor space |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for structural performance testing | |
|---|---|---|
| EN 13986:2004 | Wood-based panels for construction, applicable for formaldehyde emission verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance, recommended for commercial procurement |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Limit of formaldehyde emission for wooden furniture, required for indoor air quality compliance | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for core material performance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for dimensional and structural acceptance; 2. GB 18584-2001: Limit of formaldehyde emission for wooden furniture, required for indoor air quality compliance; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable for core material performance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
