Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall desk dimensions | 1680 x 800 x 760 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| Edge band thickness | 3 mm | |
| Knee clearance width | 680 mm | |
| Knee clearance height | 660 mm | |
| Knee clearance depth | 500 mm | |
| Right drawer pedestal width | 420 mm | |
| Individual drawer internal dimensions | 360 x 450 x 140 mm | |
| Pull-out keyboard tray dimensions | 590 x 290 mm | |
| Left storage cabinet internal dimensions | 400 x 500 x 600 mm | |
| Cable grommet diameter | 60 mm | |
| Base panel thickness | 18 mm | |
| Modular L-return matching dimensions | 1200 x 450 x 760 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 204 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Net weight (single pedestal desk) | 64 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate | 25mm thick MDF/particleboard core | |
|---|---|---|
| Surface finish | Thermally fused reddish brown melamine veneer | |
| Edge treatment | 3mm thick PVC bullnose edge banding | |
| Structural side panels | 18mm thick engineered wood solid panels | |
| Drawer and cabinet hardware | Zinc alloy pull handles, steel cam-lock assembly | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension glides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated cable management | Two 60mm desktop grommets routed to under-desk cable channel | |
|---|---|---|
| Locking storage system | Keyed cam lock secures all three right-side drawers | |
| Pull-out keyboard tray | Smooth sliding tray mounted at 660mm floor height | |
| Adjustable leveling glides | Threaded floor glides at each base corner compensate for uneven floors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private executive office | Suitable for manager or director workspaces with integrated document storage | |
|---|---|---|
| General administrative workspace | Configurable for clerical or administrative staff with cable routing for computers |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables and desks, safety and strength requirements for commercial use | |
|---|---|---|
| EN 15372:2008 | Furniture, strength, durability and safety requirements for non-domestic storage units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for load and durability performance testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable for drawer and cabinet performance requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable for desk structural stability | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for engineered wood substrate performance | |
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable for desk structural stability; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for engineered wood substrate performance; 3. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
