Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1400 x 700 x 760 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 100 kg | |
|---|---|---|
| Recommended user weight capacity | 136 kg | |
| Net product weight | 75 kg | |
| Design service life | 8 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop panel | 25mm thick MDF core with red wood veneer, high gloss PU lacquer finish | |
|---|---|---|
| Edge trim | Solid hardwood matching veneer color, polished smooth edge | |
| Pedestal panels | 18mm thick particleboard with matching wood grain laminate | |
| Drawer hardware | Chrome plated steel pull handles, 3-section ball bearing drawer slides | |
| Lock mechanism | Keyed cam lock on top drawer, secures all 3 pedestal drawers | |
| CPU trolley casters | 50mm diameter black PVC swivel casters, 2 with brake function |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Two desk-top grommets route power and data cables from work surface to floor | |
|---|---|---|
| Pedestal storage | 3 vertically stacked lockable drawers on left side for document and supply storage | |
| CPU support | Pull-out rolling trolley under right desk side holds desktop computer tower for easy access | |
| Privacy modesty panel | Full-height rear panel blocks view of under-desk area from front and sides |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private offices | Suitable for management workspaces requiring formal traditional aesthetic and integrated storage | |
|---|---|---|
| Government and institutional offices | Appropriate for state-owned enterprise and administrative spaces with formal furniture requirements |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable for office work desk dimensional and safety requirements | |
|---|---|---|
| EN 13722:2004 | Applicable for strength and durability of office storage pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable for desk products performance and durability test requirements | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable for storage pedestal strength and cycle performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture | |
|---|---|---|
| GB/T 4897.3-2003 | Applicable for particleboard used in furniture structural components | |
| GB 18584-2001 | Applicable for formaldehyde emission limits of wooden furniture interior materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture; 2. GB/T 4897.3-2003: Applicable for particleboard used in furniture structural components; 3. GB 18584-2001: Applicable for formaldehyde emission limits of wooden furniture interior materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
