Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2200 x 900 x 750 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat depth per position | 580 mm | |
| Single seat width | 620 mm | |
| Backrest height above seat | 330 mm | |
| Armrest height above seat | 200 mm | |
| Armrest width | 180 mm | |
| Leg height under seat base | 120 mm | |
| Under-seat ground clearance | 120 mm | |
| Cushion thickness (seat) | 180 mm | |
| Cushion thickness (back) | 150 mm | |
| Distance between front arm edges | 1840 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total static load capacity | 300 kg | |
|---|---|---|
| Product net weight | 75 kg | |
| Foam density (seat) | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 30000 Martindale cycles | |
| Seam stitching pitch | 8 stitches per 30mm | |
| Applicable user count | 3 adults | |
| Frame static load durability | 100000 cycle test reference | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Inner load-bearing frame | Solid kiln-dried pine wood, 30mm section, glued and screwed joints | |
|---|---|---|
| Upholstery fabric | 300gsm polyester fabric, teal color, gathered pleated texture | |
| Seat cushion fill | High-density polyurethane foam wrapped with 20mm soft polyester fiber | |
| Back cushion fill | 28kg/m³ soft polyurethane foam with fiber wrap | |
| Support legs | 15mm diameter black powder-coated carbon steel tube, four point support | |
| Seat support base | 12mm plywood decking secured to wood frame | |
| Armrest internal structure | Curved plywood frame wrapped with foam padding, integrated with main frame | |
| Frame surface treatment | Moisture-resistant sealant on wood frame to prevent warping | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed straight three-seat layout with separate aligned cushions | |
|---|---|---|
| Cushion attachment | Non-removable fixed cushions secured to frame base | |
| Support structure | Elevated metal leg base with full open under-seat clearance for floor cleaning | |
| Posture support | Low-angle backrest designed for relaxed upright lounge seating | |
| Structural reinforcement | Central support leg positioned under middle seat bay to prevent sagging | |
| Maintenance access | Smooth woven fabric surface suitable for regular vacuuming and spot cleaning | |
| Assembly requirement | Legs attach to pre-assembled upholstered frame on delivery | |
| Floor protection | Plastic glide pads fitted to bottom of each metal leg to prevent floor scratches | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room | Primary seating piece facing a coffee table for casual daily use and guest reception | |
|---|---|---|
| Modern apartment interiors | Soft rounded silhouette and teal finish fits minimalist, contemporary, Nordic design schemes | |
| Office lounge areas | Suitable for informal waiting zones or breakout spaces in creative work environments | |
| Showroom and staging applications | Upholstered form works for property display and furniture showroom presentation | |
| Small open-plan spaces | Low profile and slender leg base creates visual lightness in compact living areas | |
| Hospitality guest areas | Appropriate for boutique hotel lobbies or lounge seating in casual F&B venues |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture strength, durability and safety requirements for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance to smouldering cigarette |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to inner wood frame | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, for indoor air safety | |
| GB/T 1952.1-2012 | Technical specifications for upholstered sofas, covering strength and durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to inner wood frame; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, for indoor air safety; 3. GB/T 1952.1-2012: Technical specifications for upholstered sofas, covering strength and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
