3-Piece Modular Curved Reception Lounge Seating Set with Round Coffee Table (model CURV-RC3-800TB) is listed under Fabric Office Sofa, with overall dimensions of 3200 × 3200 × 800 mm and main material of textile crafts. Load capacity: 50 kg. Certifications: modular,construction,commercial,furniture,two-tone,upholstered,design,circular,conversational,layout. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled circular footprint diameter | 3200 mm | |
|---|---|---|
| Individual C-shaped curved sofa unit outer arc length | 2300 mm | |
| Individual sofa unit maximum depth (front to back of arc) | 700 mm | |
| Sofa seat height from floor to seating surface | 450 mm | |
| Sofa total height (seat to top of backrest) | 800 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest thickness at padded surface | 100 mm | |
| Sofa support leg height | 100 mm | |
| Central round coffee table diameter | 800 mm | |
| Coffee table total height from floor to table top | 550 mm | |
| Coffee table 4-star cross base leg spread diameter | 600 mm | |
| Chrome table support column diameter | 60 mm | |
| Backrest height above seating surface | 350 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total seating capacity for full 3-unit set | 8 persons | |
|---|---|---|
| Per-seat static weight capacity | 136 kg | |
| Coffee table top static load capacity | 50 kg | |
| Total set net weight (3 sofas + 1 table) | 400 kg | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Frame static load durability | 100000 cycles | |
| Limited commercial warranty | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and main body upholstery | Black PU faux leather, 1.2mm thickness, stain-resistant wipe-clean finish | |
|---|---|---|
| End and backrest accent upholstery | Red PU faux leather, 1.2mm thickness, matching wear-resistant finish | |
| Seat and backrest padding | High-resilience polyurethane foam, CFC-free, commercial grade | |
| Sofa internal support frame | Solid kiln-dried pine wood + welded steel inner frame, 25mm steel tube thickness | |
| Sofa support legs | Polished chrome-plated steel legs, 2mm wall thickness, with non-slip floor glides | |
| Coffee table tabletop | Light wood-look high-pressure laminate, 25mm thickness, PVC edge banding |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular unit connection | Metal ganging clips under each sofa unit to lock modules in circular layout | |
|---|---|---|
| Floor protection | Non-marking rubber glides on all sofa legs and table base feet, prevents floor scratches | |
| Table leveling adjustment | Adjustable feet on table base to compensate for uneven floor surfaces | |
| Upholstery maintenance | Stain and spill resistant surface, wipe clean with mild detergent for commercial upkeep |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception and waiting areas | Circular conversational layout supports face-to-face guest interaction and waiting comfort | |
|---|---|---|
| Hotel and salon lobby spaces | Two-tone professional appearance matches commercial public area decor requirements |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture - Strength, durability and safety for non-domestic seating, applicable to reception sofas | |
|---|---|---|
| EN 15372:2016 | Furniture - Strength, durability and safety for non-domestic tables, applicable to coffee table | |
| EN 1021-1:2014 | Furniture - Upholstery ignition resistance (smouldering cigarette), recommended for public spaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge seating standard for strength, durability and structural integrity in commercial spaces | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to coffee table load and stability testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate table top and inner wood frame | |
|---|---|---|
| GB 20400-2006 | Limit of harmful substances in leather and fur, applicable to PU/upholstery material safety | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to coffee table strength verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate table top and inner wood frame; 2. GB 20400-2006: Limit of harmful substances in leather and fur, applicable to PU/upholstery material safety; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to coffee table strength verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
