Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2010 x 800 x 1900 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat depth | 580 mm | |
| Single seat width | 800 mm | |
| Backrest height above seat | 420 mm | |
| Support leg height | 200 mm | |
| Side panel thickness | 60 mm | |
| Sloped hood peak height | 1900 mm | |
| Under-seat floor clearance | 180 mm | |
| Armrest height above seat | 180 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total static load capacity | 300 kg | |
|---|---|---|
| Seat foam density | 45 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Acoustic noise reduction | 32 dB | |
| Seat foam thickness | 100 mm | |
| Back foam thickness | 80 mm | |
| Net product weight | 120 kg | |
| Fabric abrasion resistance | 50000 Martindale cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Inner seating upholstery | Mint green velvet fabric, 350 g/m² | |
|---|---|---|
| Exterior panel fabric | Grey textured polyester acoustic fabric | |
| Acoustic panel core | Polyester fiber sound-absorbing fill | |
| Inner structural frame | 18 mm thick birch plywood frame | |
| Seat support system | 40 mm wide elastic webbing, 1.5 mm sinuous springs | |
| Legs and base frame | 1.5 mm thick powder-coated black cold-rolled steel | |
| Seat cushion fill | High-density polyurethane foam with Dacron wrap | |
| Seam construction | 8 stitches per inch reinforced stitching | |
| Panel edge trim | Matching fabric welt edge finishing | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Acoustic privacy enclosure | Three-sided wrap with sloped upper hood reduces conversational distraction in open offices | |
|---|---|---|
| Seating configuration | Two-seat fixed bench layout with integrated padded armrests | |
| Floor clearance | 180 mm open space under the booth allows robotic vacuum access and under-seat cable routing | |
| Fixed installation | Four legs with adjustable leveling glides stabilize on uneven commercial flooring | |
| Upholstery customization | Fabric color and material can be specified to match office interior schemes | |
| Access orientation | Open front design allows unobstructed entry from the front side only | |
| Surface cleanability | Stain-repellent contract fabric allows spot cleaning with standard upholstery cleaners | |
| Optional add-on compatibility | Supports integrated USB power modules and LED task lighting as project upgrades | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Packaging material | 5-layer corrugated carton with corner foam protection, non-supplier specification | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Open-plan office collaboration zones | Semi-enclosed seating for small impromptu meetings without sound disruption to nearby staff | |
|---|---|---|
| Office reception waiting areas | Provides semi-private seating for guests waiting for appointments | |
| Coworking space quiet lounge zones | Creates low-distraction spots for focused relaxation or short one-on-one conversations | |
| Corporate breakout areas | Comfortable enclosed lounge seating for informal team discussions | |
| Higher education common spaces | Semi-private seating for student group work or quiet study in campus buildings | |
| Public library lounge zones | Reduced-noise seating for reading or quiet conversations near public work areas |
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Office furniture visitor seating, applicable to strength and stability testing | |
|---|---|---|
| EN 1022:2018 | Domestic and contract seating stability test method for safe use verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Lounge and public seating standard for durability, strength and safety | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and social responsibility |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to plywood frame structural integrity | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for interior air quality compliance | |
| GB/T 19001-2016 | Quality management system requirement for commercial furniture production consistency |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to plywood frame structural integrity; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for interior air quality compliance; 3. GB/T 19001-2016: Quality management system requirement for commercial furniture production consistency; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
