Automatic mm / inch conversion · Core engineering specifications
| Overall sofa dimensions | 3380 x 1260 x 830 mm | |
|---|---|---|
| Seat height | 420 mm | |
| Seat depth | 680 mm | |
| Seat width per central segment | 780 mm | |
| Chaise end extension length | 760 mm | |
| Lounge chair overall dimensions | 790 x 650 x 880 mm | |
| Coffee table overall dimensions | 1400 x 800 x 420 mm | |
| Side table overall dimensions | 500 x 500 x 550 mm | |
| Backrest height (sofa) | 410 mm | |
| Throw pillow dimensions | 450 x 450 mm | |
| Clearance under sofa base | 10 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total sofa static load capacity | 500 kg | |
|---|---|---|
| Foam density (seat cushions) | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 30000 Martindale cycles | |
| Net weight (sofa) | 140 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa upholstery | 1.2mm thick terracotta polyester velvet | |
|---|---|---|
| Sofa inner frame | 30mm thick kiln-dried solid pine | |
| Seat cushion core | Multi-layer high-density polyurethane foam | |
| Back cushion core | 35kg/m³ medium-density foam | |
| Sofa base trim | Matched velvet upholstered plinth | |
| Coffee table top | 12mm thick white sintered stone | |
| Coffee table base | Brushed gunmetal stainless steel loop frame | |
| Lounge chair frame | 20mm diameter powder-coated black carbon steel sled base | |
| Lounge chair upholstery | Two-tone terracotta and rust red velvet | |
| Side table components | 10mm thick white sintered stone top | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Modular connection | All sofa segments join with heavy-duty metal clip connectors | |
|---|---|---|
| Chaise lounging function | Dual integrated end chaises support full-leg recline | |
| Fixed lounge chair structure | Sled base provides stable static seating with no swivel or recline | |
| Coffee table lower storage | Rounded lacquered plinth under tabletop provides open display storage | |
| Floor protection | All furniture feet fitted with non-marking silicone pads | |
| Cushion non-slip design | Seat cushions secured with hidden hook-and-loop fasteners | |
| Fixed side table design | Low-profile weighted base prevents tipping | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential living room lounge layout | Suitable for open-concept modern living rooms to define a central conversational seating zone | |
|---|---|---|
| High-end residential reception area | Fits luxury apartment lobbies or private lounge spaces for guest seating | |
| Boutique hotel lounge space | Appropriate for boutique hotel suite seating areas matching contemporary soft furnishing schemes | |
| Designer showroom display | Ideal for furniture showroom curation showcasing curved modern furniture silhouettes | |
| Executive breakout area | Suitable for informal office breakout zones for relaxed employee or guest seating | |
| Recommended pairing | Pairs with low-pile geometric area rugs to define the seating zone without obstructing the curved silhouette | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Domestic furniture - Seating - Determination of stability, applicable to sofa and chair tip testing | |
|---|---|---|
| EN 13759:2004 | Domestic furniture - Seating - Test methods for durability, applicable to long-term load testing |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to sofa wood frame quality | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing | |
| GB/T 19876-2005 | Performance test methods for sofas, applicable to durability and stability evaluation |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to sofa wood frame quality; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing; 3. GB/T 19876-2005: Performance test methods for sofas, applicable to durability and stability evaluation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
