| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall sofa dimensions | 3200 x 1600 x 780 mm | |
|---|---|---|
| Seat height from floor | 420 mm | |
| Seat depth per module | 680 mm | |
| Backrest height above seat | 360 mm | |
| Single curved sofa module dimensions | 1070 x 800 x 780 mm | |
| Large central coffee table dimensions | 900 x 900 x 450 mm | |
| Small side coffee table dimensions | 600 x 600 x 480 mm | |
| Cylindrical ottoman dimensions | 450 x 450 x 420 mm | |
| Sofa wall thickness (arm/back panel) | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Sofa set total weight range | 120 kg | |
|---|---|---|
| Single sofa module static load capacity | 300 kg | |
| Sofa seating capacity | 6 persons | |
| Fabric abrasion resistance reference | 30000 Martindale cycles | |
| Foam density (seat/back) | 38 kg/m³ seat, 28 kg/m³ back | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat cushion upholstery | Teal polyester fabric with tight fit upholstery | |
|---|---|---|
| Backrest and arm upholstery | Light off-white polyester fabric with matching tight upholstery | |
| Internal seating frame | 15 mm thick E0 grade composite wood frame with glued and stapled joints | |
| Seat cushion padding | 80 mm thick high resilience polyurethane foam | |
| Backrest padding | 60 mm thick medium density polyurethane foam | |
| Large coffee table base | Powder-coated matte light gray steel 4-star cross base | |
| Small side coffee table legs | Clear lacquered natural solid beech wood legs, 30 mm diameter, 3-point support | |
| Coffee table tops | 18 mm thick MDF core with matte white melamine finish, rounded edge treatment | |
| Ottoman upholstery | Polyester fabric in available green/blue/red color options, black non-slip fabric base | |
| Sofa module mobility hardware | 30 mm diameter swivel plastic casters, 2 per module | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Modular sectional reconfiguration | 3 independent curved sections with casters can be arranged as full semicircle, split into individual curved benches, or combined into other curved layouts for different space shapes | |
|---|---|---|
| Auxiliary expandable seating | Upholstered cylindrical ottomans provide additional portable seating that can be placed anywhere around the arrangement, or used as temporary footrests | |
| Caster mobility for seating sections | Low-profile swivel casters allow each sofa section to be rolled for cleaning or layout adjustment, with non-marking wheels suitable for hard wood or vinyl commercial flooring | |
| Fixed non-tilting back support | Curved integrated backrest follows the semicircular shape, provides consistent mid-back support across all seating positions without adjustment mechanisms | |
| Color customization option | Upholstery is available in multiple fabric colors for seats, backs and ottomans to match existing interior decor schemes | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Total shipping packages | 7 pieces | |
|---|---|---|
| Largest carton dimensions (sofa module) | 1100 x 830 x 810 mm | |
| Total shipping gross weight | 160 kg | |
| Total shipment volume | 1.8 CBM | |
| On-site assembly time | 60 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| 40ft HQ container loading quantity | 46 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Office reception and waiting areas | Semicircular layout creates an inviting enclosed conversation area for visitor waiting, client meetings and casual guest reception in corporate lobbies | |
|---|---|---|
| Public lounge and breakout spaces | Modular mobile sections work for office breakout zones, library reading lounges and student common areas, supporting both group gatherings and individual relaxation | |
| Healthcare and clinic waiting zones | Durable commercial grade fabric and easy-move casters support frequent cleaning and layout changes in high-traffic patient waiting areas, with soft edges for user safety | |
| Educational institution common areas | Bright color options and expandable ottoman seating suit student collaboration spaces, dormitory common rooms and campus lounge areas for casual group work and socializing | |
| Retail and hospitality waiting zones | Two-tone modern design fits beauty salons, boutique retail fitting areas and hotel lobbies, providing flexible guest seating that can be rearranged for events | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture - Strength, durability and safety requirements for domestic seating, applicable as minimum performance benchmark for commercial reception seating strength | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability, applicable to verify anti-tip performance of curved sofa modules and freestanding ottomans | |
| EN 15372:2016 | Furniture - Durability requirements for tables for non-domestic use, applicable to verify coffee table load capacity and leg joint durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural frame durability and dimensional stability of sofa and table components | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wood furniture, applicable for formaldehyde emission verification of composite wood components used in frames and table tops | |
| GB/T 1952.1-2012 | Technical requirements for upholstered furniture sofas, applicable to seating durability, foam performance and upholstery strength of the modular sofa units |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural frame durability and dimensional stability of sofa and table components; 2. GB 18584-2001: Limit of harmful substances in wood furniture, applicable for formaldehyde emission verification of composite wood components used in frames and table tops; 3. GB/T 1952.1-2012: Technical requirements for upholstered furniture sofas, applicable to seating durability, foam performance and upholstery strength of the modular sofa units; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
