Automatic mm / inch conversion · Core engineering specifications
| Overall L-shape dimensions | 2800 x 1800 x 790 mm | |
|---|---|---|
| Seat height from floor | 480 mm | |
| Individual seat depth | 600 mm | |
| Single module unit size | 900 x 900 mm | |
| Backrest height above seat | 310 mm | |
| Armrest height above seat | 310 mm | |
| Plinth base height | 30 mm | |
| Throw cushion size | 400 x 400 mm | |
| Armrest width | 200 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total sofa weight | 90 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Seat foam density | 50 kg/m³ | |
| Back cushion foam density | 25 kg/m³ | |
| Fabric Martindale abrasion resistance | 30000 cycles | |
| Seam stitch pitch | 30 mm | |
| Metal connector salt spray resistance | 48 hours | |
| Frame moisture content | 12% | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main upholstery fabric | 380gsm chenille woven fabric, olive and chartreuse two-tone | |
|---|---|---|
| Seat cushion fill | 50D high-resilience polyurethane foam core | |
| Back cushion fill | 25D soft polyurethane foam with fiber wrap | |
| Internal load-bearing frame | Kiln-dried solid pine with plywood reinforcement | |
| Seat support system | 80mm elastic webbing + sinuous spring suspension | |
| Modular connecting hardware | Powder-coated stainless steel interlocking buckles | |
| Base trim | Black matte PVC plinth wrapping, non-marking floor contact | |
| Throw cushion fill | Hollow conjugate polyester fiber fill | |
| Fabric surface treatment | Stain-repellent fabric finish for residential care | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Modular layout reconfiguration | Interlocking square modules connect to form L, U or straight layouts | |
|---|---|---|
| Floor protection | Non-marking fabric/felt base contact pads prevent floor scuffing | |
| Seating capacity | 4 adults plus chaise/ottoman extended footrest use | |
| Module alignment tolerance | ±2 mm precision fit between connected units | |
| Rounded edge safety | All external corners fully padded with rounded 100mm radius edges | |
| Vacuum-compressed shipping option | Seat modules compress for reduced shipping volume | |
| Integrated armrest function | Padded armrests double as headrests for reclined lounge positions | |
| Color blocking customization | Two-tone olive/chartreuse module mix supports custom color layout | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room main seating | Large L-shape configuration provides 4-person seating for apartment or family lounges | |
|---|---|---|
| Open-plan office lounge | Soft rounded design suits informal collaboration and break-out waiting areas | |
| Small studio flexible furnishing | Reconfigurable modules adapt to different room layouts without fixed installation | |
| Modern minimalist interior schemes | Two-tone olive green palette complements contemporary wabi-sabi and Japandi decor | |
| Hotel lobby casual seating | Low-profile block design creates modular clustered seating for boutique public spaces | |
| Family home play area seating | Padded rounded edges reduce impact injury risk for household use |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Residential furniture strength, durability and safety requirements for seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance to smoldering cigarette |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame sofa structure | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit for interior decoration wooden furniture, E1 grade ≤0.124mg/m³ recommended | |
| GB/T 1952.1-2012 | Test methods for upholstered sofas, static load and durability testing reference |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame sofa structure; 2. GB 18584-2001: Formaldehyde emission limit for interior decoration wooden furniture, E1 grade ≤0.124mg/m³ recommended; 3. GB/T 1952.1-2012: Test methods for upholstered sofas, static load and durability testing reference; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
