Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1000 x 910 x 1300 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Seat width (clear inner) | 750 mm | |
| Seat depth (clear inner) | 580 mm | |
| Integrated side work surface size | 400 x 300 mm | |
| Work surface height above seat | 250 mm | |
| Backrest total height | 850 mm | |
| Leg height (floor to seat base) | 270 mm | |
| Enclosure panel thickness | 80 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per unit | 40 kg | |
|---|---|---|
| Maximum static load capacity | 180 kg | |
| Upholstery fabric abrasion resistance | 50000 Martindale cycles | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Back foam rebound rate | 60% | |
| Recommended maximum seated duration | 240 minutes | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer shell upholstery | Woven polyester-blend boucle fabric | |
|---|---|---|
| Internal support frame | Solid pine + engineered plywood board | |
| Seat padding core | High-density polyurethane foam | |
| Back padding core | Medium-density polyurethane foam | |
| Support legs | Powder-coated matte black steel tube | |
| Integrated side table top | White matte laminated MDF panel | |
| Table support frame | Chrome-plated steel wire legs | |
| Seam construction | Reinforced stitched seams with 8mm stitch pitch | |
| Decorative throw pillow | Polyester fiber fill with matching fabric cover | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Semi-enclosed sightline block | 1200mm+ tall curved wrap panels block peripheral visual distraction | |
|---|---|---|
| Integrated fixed side work surface | Rigid flat table mounted to chair side for writing, devices or refreshments | |
| Fixed non-reclining seat structure | Stable static seating position with no tilt, swivel or height adjustment | |
| Curved integrated lumbar support | Raised padded section in lower back aligns with natural spine curve | |
| Floor protection glides | Small plastic glides on leg bases prevent floor scratching | |
| Removable accent pillow | Included throw pillow can be repositioned for extra back or neck support | |
| Modular color customization | Upholstery and pillow fabrics available in multiple commercial-grade color options | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Open office focus zones | Provides semi-private individual seating for short focused work or calls | |
|---|---|---|
| Corporate lounge and breakout areas | Serves as informal seating for breaks, casual conversations or refreshments | |
| Library and co-working quiet areas | Supports individual reading or laptop use with integrated work surface | |
| Healthcare and public waiting areas | Offers personal space for visitors in high-traffic public waiting zones | |
| Hotel lobby and reception spaces | Creates discrete seating nooks for guests to work or wait | |
| Higher education campus common areas | Provides private study seating for students in student union or library spaces | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Office furniture - Lounge seating, test methods for strength and stability | |
|---|---|---|
| EN 1021-1:2014 | Furniture upholstery fire resistance, cigarette ignition resistance requirement |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge and public seating standard for durability, strength and stability | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and environmental impact |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to inner frame structure | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission control | |
| GB/T 19889.3-2005 | Acoustics measurement reference for sound insulation performance if specified |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to inner frame structure; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission control; 3. GB/T 19889.3-2005: Acoustics measurement reference for sound insulation performance if specified; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
