Automatic mm / inch conversion · Core engineering specifications
| Overall external dimensions | 1800 x 1200 x 1350 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total product weight | 145 kg | |
|---|---|---|
| Seat static load capacity per seat | 150 kg | |
| Seating capacity | 2 users | |
| Acoustic noise reduction rating | 25 dB | |
| Recommended maximum monitor size | 24 inch | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Privacy panel upholstery | Polyester commercial fabric, horizontal channel tufting | |
|---|---|---|
| Panel padding core | High-density polyurethane foam, 40 kg/m³ density | |
| Booth support frame | Polished chrome-plated steel tube, 25 mm diameter | |
| Table top surface | Matte white engineered quartz composite, 20 mm thickness | |
| Table support column | Brushed 304 stainless steel, 60 mm diameter | |
| Table base plate | Black powder-coated steel, 8 mm thickness | |
| Seat cushion core | High-resilience polyurethane foam, 45 kg/m³ density | |
| Internal panel structure | Plywood backing board, 12 mm thickness | |
| Display mount backing | Reinforced steel mounting plate | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Seating layout | Face-to-face dual bench seats arranged for two-person collaborative discussion | |
|---|---|---|
| Privacy screening | Full-height side and rear upholstered panels block line of sight to reduce distraction | |
| Display integration | Central rear panel includes reinforced mount for fixed monitor installation | |
| Work surface support | Central fixed pedestal table provides shared surface for devices, documents and refreshments | |
| Leg clearance under table | 670 mm vertical clearance from floor to table underside | |
| Acoustic dampening | Upholstered padded panels reduce reflected sound and speech transmission within open offices | |
| Floor installation | Fixed metal footings secure booth to finished floor for stability | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference shipping carton dimensions | 1850 x 1250 x 300 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office huddle spaces | Provides private enclosed seating for impromptu 2-person meetings without separate room construction | |
|---|---|---|
| Corporate co-working areas | Offers acoustic privacy for video calls, quick discussions and collaborative work in shared spaces | |
| Office reception waiting zones | Creates semi-private waiting area for visitors with space for device use and refreshments | |
| Corporate training facilities | Supports small group breakout discussions and paired learning activities | |
| Quiet focus work zones | Serves as dedicated small space for focused individual work with screen and writing surface | |
| Healthcare and public facility consultation areas | Provides semi-private seating for short confidential conversations between staff and visitors |
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Applicable to strength, durability and safety requirements for office seating | |
|---|---|---|
| EN 15372:2016 | Applicable to safety, strength and durability requirements for office non-domestic tables | |
| EN 1022:2019 | Applicable to stability testing for domestic and non-domestic seating units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Applicable to performance and safety requirements for lounge and public area seating | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Applicable to performance requirements for desk products used in office environments | |
| ANSI/BIFMA X7.1-2022 | Applicable to formaldehyde and TVOC emission limits for office furniture systems |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable to general technical requirements for wooden and upholstered office furniture structural safety | |
|---|---|---|
| GB/T 24821-2009 | Applicable to office furniture desk and table surface strength and durability requirements | |
| GB 18584-2001 | Applicable to interior decoration material formaldehyde emission limits for wooden furniture components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable to general technical requirements for wooden and upholstered office furniture structural safety; 2. GB/T 24821-2009: Applicable to office furniture desk and table surface strength and durability requirements; 3. GB 18584-2001: Applicable to interior decoration material formaldehyde emission limits for wooden furniture components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
