Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1550 x 850 x 840 mm | |
|---|---|---|
| Seat height | 460 mm | |
| Seat depth | 580 mm | |
| Seat width | 1500 mm | |
| Backrest height | 380 mm | |
| Backrest thickness | 120 mm | |
| Seat cushion thickness | 120 mm | |
| Leg tubing cross-section | 50 x 25 mm | |
| Floor clearance under seat | 120 mm | |
| Seat front edge radius | 50 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Product net weight | 50 kg | |
|---|---|---|
| Total static load capacity | 360 kg | |
| Seat foam density | 29 kg/m³ | |
| Foam rebound rate | 40% | |
| Foam compression set | 8% | |
| Upholstery abrasion resistance | 50000 cycles | |
| Recommended number of users | 2 | |
| Frame static load rating | 450 kg | |
| Commercial warranty period | 1 year | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat upholstery | Dark brown faux leather (PU), stain-resistant, wipe-clean surface | |
|---|---|---|
| Backrest upholstery | Tan faux leather (PU), color-matched durable surface | |
| Seat cushion fill | High-density polyurethane foam, uniform support core | |
| Backrest cushion fill | Medium-density polyurethane foam, supportive lumbar pad | |
| Internal support frame | Powder-coated steel inner frame, anti-corrosion treated | |
| Support legs | Polished 304 stainless steel open sled legs, mirror finish | |
| Floor protection pads | Non-slip rubber pads at leg base, anti-scratch for hard floors | |
| Seam stitching | High-strength polyester thread, 8 stitches per 30mm pitch | |
| Edge finishing | Rounded sealed upholstery edges, no exposed raw material | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed armless two-seat layout, no dividers between seating positions | |
|---|---|---|
| Position adjustment | Stationary fixed design, no recline, swivel or height adjustment | |
| Convertibility | Fixed upright position, no fold-down or sofa-bed conversion mechanism | |
| Cleaning access | 120mm floor clearance allows robotic vacuum and mop access under seat | |
| Floor stability | Four contact points on sled base, no rocking or tilting on level hard floors | |
| Surface maintenance | Wipe-clean faux leather surface, resistant to common office stains | |
| Assembly requirement | Knock-down leg attachment, legs bolt to pre-installed seat frame inserts | |
| Stacking capability | Non-stackable fixed upholstered form, designed for permanent placement | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 1600 x 900 x 500 mm | |
|---|---|---|
| Gross shipping weight | 55 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Office reception areas | Suitable for visitor waiting zones outside meeting rooms or executive offices | |
|---|---|---|
| Public service lobbies | Durable easy-clean surface ideal for bank, clinic or government hall waiting areas | |
| Breakout collaboration spaces | Compact armless design fits small informal meeting areas for quick discussions | |
| Training room side seating | Can be placed along walls for temporary attendee overflow seating | |
| Commercial entryways | Sleek minimalist metal base fits modern retail or showroom entry waiting zones | |
| Healthcare waiting areas | Wipe-clean surface supports regular sanitization per public health requirements |
EU Market Access Requirements* EN Standards
| EN 13759:2004 | Applicable standards and test results require confirmation | |
|---|---|---|
| EN 1022:2005 | Applicable standard for upholstered furniture seating durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Applicable standards and test results require confirmation |
|---|
Standards applicable to China-market projects
| GB/T 16799-2008 | Applicable standards and test results require confirmation | |
|---|---|---|
| GB 18584-2001 | Applicable standards and test results require confirmation |
This product must meet the following technical requirements: 1. GB/T 16799-2008: Applicable standards and test results require confirmation; 2. GB 18584-2001: Applicable standards and test results require confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
