PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1500 × 900 × 1600 mm
Overall footprint	1500 x 900 x 1600 mm
Seat height from floor	450 mm
Worktable height from floor	750 mm
Worktable surface size	600 x 500 mm
Acoustic panel thickness	60 mm
Seat depth	500 mm
Seat width	800 mm
Backrest divider height above seat	1150 mm
Leg height (panel/seat/table supports)	150 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Seating static load capacity	150 kg
Perceived noise reduction	32 dB
Net unit weight	120 kg
User capacity	1 person
Acoustic panel sound absorption coefficient	0.85 NRC
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Privacy panel exterior	Woven contract-grade polyester acoustic fabric
Privacy panel core	50mm polyester fiber acoustic fill
Panel internal frame	1.2mm powder-coated steel tube
Bench seat cushion	40mm high-density CAL 117-compliant polyurethane foam
Bench upholstery	Stain-resistant commercial woven polyester fabric
Worktable top	18mm high-pressure laminate (HPL) on particleboard core
Support legs (panels, seat, table)	25mm diameter powder-coated black steel tube
Modular panel connectors	Injection-molded black plastic clips
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Visual and acoustic screening	Three-sided U-shaped tall panels block seated sightlines and reduce reverberation
Modular connection	Integrated edge clips allow adjacent booths to link into grouped configurations
Freestanding installation	Units rest on short metal legs without required wall or floor anchoring
Integrated work surface	Fixed compact table positioned at seated work height inside the booth enclosure
Open-entry access	No door or closure on the front opening for quick entry and exit
Optional power integration	Pre-drilled panel channels support retrofit of USB/power outlets on table edge
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office focus zones	Provides semi-private space for individual focused work without permanent construction
Co-working space individual work areas	Offers modular, relocatable private seating for flexible hot-desking environments
Office quiet zones for calls and reading	Reduces ambient noise for short calls, reading or laptop-based task work
Public lobby and waiting area work nooks	Creates discrete temporary work spaces for visitors in reception zones
Education and library study zones	Provides individual semi-enclosed study seating for students or researchers

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1023-1:2000	Applicable for stability, strength and durability of office work furniture
EN 13722:2019	Applicable for acoustic performance of office furniture privacy screens
EN 1021-1:2014	Applicable for upholstered furniture ignitability by smoldering cigarette

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.11-2015	Applicable for strength and stability of free-standing office privacy panels
ANSI/BIFMA X5.4-2021	Applicable for durability and safety of lounge/office public seating

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 19889.3-2005	Applicable for measuring airborne sound insulation of office partition panels
GB 20286-2006	Applicable for fire performance requirements of public place upholstered furniture
GB/T 35607-2017	Applicable for green product evaluation of furniture with low VOC emissions

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 19889.3-2005: Applicable for measuring airborne sound insulation of office partition panels;
2. GB 20286-2006: Applicable for fire performance requirements of public place upholstered furniture;
3. GB/T 35607-2017: Applicable for green product evaluation of furniture with low VOC emissions;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · AOB-U1-1600

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · AOB-U1-1600

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · AOB-U1-1600Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Semi-Enclosed Single-Seat Acoustic Office Focus Booth with Integrated Bench and Worktable (model AOB-U1600) is an unbranded modular acoustic privacy solution designed to deliver dedicated semi-private space without permanent built modifications.
Visually, the unit features a three-sided U-shaped semi-enclosed structure framed by tall, fabric-upholstered acoustic panels that extend 1150 mm above the seat, fully blocking seated sightlines for adjacent occupants. The integrated upholstered bench sits opposite the open, doorless front entry, paired with a fixed compact laminate worktable positioned within the enclosure. The design uses consistent woven fabric finishes across privacy panels and seating, paired with matte black powder-coated steel legs for a streamlined, professional aesthetic that complements a range of commercial interior palettes.
The booth is constructed for heavy contract use: 60 mm thick acoustic panels use a 1.2 mm powder-coated steel tube internal frame, filled with 50 mm polyester fiber acoustic fill and wrapped in contract-grade woven polyester fabric on exterior surfaces. The bench cushion uses 40 mm high-density CAL 117-compliant polyurethane foam upholstered in stain-resistant commercial woven polyester, while the worktop is formed from 18 mm high-pressure laminate on a particleboard core. All structural elements are supported by 25 mm diameter powder-coated black steel tube legs, with injection-molded black plastic clips serving as modular panel connectors. The structure supports a 150 kg static seating load, delivers 32 dB of perceived noise reduction, and carries a 0.85 NRC sound absorption rating for its acoustic panels.
Functionally, the freestanding unit requires no wall or floor anchoring, and integrated edge clips allow adjacent booths to be linked into custom grouped layouts. The fixed worktable sits at 750 mm above the floor, with pre-drilled panel channels to support retrofitted USB or power outlets at the table edge. The open front entry allows quick, unobstructed entry and exit, making the booth ideal for short to medium-length use cases.
This booth is suited for open-plan office focus zones, co-working space individual work areas, office quiet zones for calls and reading, public lobby work nooks for visitors, and education or library individual study zones. For procurement, note that each unit ships in two cartons with a packaged gross weight matching its 120 kg net weight, requires 40 minutes of assembly per set, and carries a single-occupant design. When planning grouped layouts, account for the unit’s 1500 x 900 x 1600 mm overall footprint to ensure adequate circulation space around installed units.

Semi-Enclosed Single-Seat Acoustic Office Focus Booth with Integrated Bench and Worktable Specifications
