PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	2840 × 1400 × 790 mm
Seat height from floor	470 mm
Seat depth (usable)	680 mm
Seat width (total usable)	2360 mm
Backrest height above seat	320 mm
Armrest height above seat	140 mm
Rounded end armrest width	201 mm
Cushion thickness (seat)	220 mm
Back cushion thickness	180 mm
Hidden base clearance from floor	20 mm
Seat Cushion Thickness	180 mm
Leg Height / Floor Clearance	160 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total static weight capacity	476 kg
Per-seat static load capacity	119 kg
Net product weight	138 kg
Seat foam density	32D
Seat foam rebound rate	60%
Fabric abrasion resistance	30000 cycles
Seam stitch pitch	8 stitches per inch
Seat Foam Density / Rebound	40 kg/m³ / 60%
Upholstery Abrasion Reference	Fabric 60000 cycles; leather-class cover 1.4 mm
Per-seat Load Reference	130 kg/seat

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Internal support frame	Kiln-dried engineered hardwood with mortise-and-tenon joinery
Seat cushion fill	32D high-density polyurethane foam wrapped with polyester fiber
Back cushion fill	Blown polyester fiber with 5% down blend for soft support
Seat support system	3.8 mm gauge sinuous steel springs with 50 mm spacing
Upholstery fabric	Two-tone textured woven polyester blend fabric
Armrest structure	Padded wood frame wrapped in matching upholstery, rounded edge profile
Modular connection hardware	Powder-coated steel connecting brackets with integrated alignment pins
Base structure	Hidden low-profile plywood base with non-woven fabric dust cover
Throw pillow fill	100% virgin polyester fiber fill, 4 matching pillows included
Timber Frame Section / Moisture	Primary section ≥30 × 50 mm; recommended moisture 12%
Spring / Webbing Specification	Sinuous spring wire 4 mm; elastic webbing 70 mm wide
Leg Connector Specification	Reference M8-M10 with at least 1 mechanical fixing per leg

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Modular configuration	Two pre-aligned curved segments that lock into a continuous arc profile
Cushion design	Reversible seat cushions with zip-off removable covers for easy cleaning
Connection lock	Spring-loaded steel bracket locks that prevent lateral movement between modules
Floor protection	Non-marking plastic glides on base underside to prevent hard floor scratching
Seat comfort	Sinuous spring suspension that absorbs impact and reduces long-term cushion sag
Layout flexibility	End arm sections can be paired with additional modules to extend overall arc length
Cushion Service Configuration	Recommended 2removable/replaceable cushion methods

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Largest carton dimensions	2400 x 1000 x 650 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Module Carton Dimensions	2200× 1050× 850 mm
Reference Packaging Volume	1.8 m³/item
Reference Packaged Gross Weight	110 kg/item

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Residential living rooms	Fits open-plan lounge spaces as a central statement seating piece
Office reception areas	Provides soft guest seating for contemporary corporate reception zones
Hotel lounge spaces	Suitable for boutique hotel public seating areas with curated modern interiors
Apartment open-plan areas	Works in urban loft and apartment living spaces requiring curved flow layout
Configuration recommendation	Pair with low round coffee tables and complementary occasional lounge chairs

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · CURV-MOD-2840-BLU

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · CURV-MOD-2840-BLU

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · CURV-MOD-2840-BLUOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Two-Tone Blue Curved 2-Module Lounge Sofa, model CURV-MOD-2840-BLU, is a minimalist modern upholstered curved modular sofa designed for comfortable lounge seating. Delivered unbranded, it features a sleek continuous arc profile formed by two pre-aligned curved segments locked together to create a smooth, flowing silhouette. Its low, hidden base keeps visual focus on the two-tone textured woven upholstery and rounded, padded end armrests, while four matching throw pillows coordinate with the seating fabric for a finished, curated look. Fixed dimensions include an overall footprint of 2840 x 1400 x 790 mm, 470 mm seat height from the floor, 680 mm usable seat depth, 2360 mm total usable seat width, 320 mm backrest height above the seat, 140 mm armrest height above the seat, 201 mm rounded end armrest width, and 220 mm thick seat cushions. Its kiln-dried engineered hardwood frame uses mortise-and-tenon joinery for structural stability, paired with a 3.8 mm gauge sinuous steel spring seat support system spaced 50 mm apart to absorb impact and reduce long-term cushion sag. Seat cushions are filled with 32D high-density polyurethane foam wrapped in polyester fiber, with a 60% rebound rate, while back cushions use a blown polyester fiber blend with 5% down for soft support. The two-tone woven polyester blend upholstery offers 30000 cycles of abrasion resistance, with seams stitched at 8 stitches per inch for durability. Reversible seat cushions have zip-off removable covers for simple cleaning, and removable or replaceable cushion formats are supported for long-term maintenance. Spring-loaded steel bracket locks prevent lateral movement between modules, while powder-coated steel connecting brackets with integrated alignment pins enable secure attachment. The hidden low-profile plywood base includes a non-woven fabric dust cover, with non-marking plastic glides on the underside to protect hard flooring from scratches. Modular sections are compatible with additional matching modules to extend the overall arc length for larger spaces. The sofa holds a total static weight capacity of 476 kg, with a per-seat static load capacity of 119 kg, and a net product weight of 138 kg. This seating piece works well as a central statement piece in open-plan residential living rooms and urban loft apartments, where its curved profile supports natural traffic flow. It also delivers soft, contemporary guest seating for modern office reception areas and curated boutique hotel public lounge spaces. Layouts are best paired with low round coffee tables and complementary occasional lounge chairs for a cohesive seating arrangement. Procurement teams should note the product ships in 2 cartons per set, with a packaged gross weight of 110 kg per item, total packaging volume of 1.8 m³ per item, and a reference assembly time of 40 minutes per set. On-site assembly requires securing the two pre-aligned segments via the integrated locking brackets before placing cushions, and replacement cushions are available to extend the product’s usable service life.

Two-Tone Blue Curved 2-Module Lounge Sofa Specifications
