Automatic mm / inch conversion · Core engineering specifications
| Seat Cushion Thickness | 180 mm | |
|---|---|---|
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total product net weight | 145 kg | |
|---|---|---|
| Static load per seating position | 150 kg | |
| Total seating capacity | 8 persons | |
| Seat foam density | 40 kg/m³ | |
| Foam rebound rate | 45% | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seam stitching pitch | 8 stitches per 30 mm | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat upholstery (grey sections) | Matte dark grey PVC faux leather | |
|---|---|---|
| Backrest upholstery (central section) | Mustard yellow PVC faux leather | |
| Internal seat padding | High-resilience polyurethane foam | |
| Internal support frame | 15 mm thick plywood frame | |
| Modular connection hardware | Powder-coated steel connecting brackets | |
| Base bottom protection | 5 mm thick non-slip plastic floor glides | |
| Backrest inner core | Solid plywood panel with foam wrap | |
| Upholstery adhesive | Low-VOC water-based furniture adhesive | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| Double-sided seating configuration | Allows seating on both long sides of central backrest for flexible group use | |
|---|---|---|
| Modular reconfiguration | 5 independent units that can be separated to form alternate seating layouts | |
| Floor protection | Integrated glides prevent floor scratching and keep units stable on hard tile flooring | |
| Central back support | Padded backrest provides lumbar support for users seated on either side | |
| Stain-resistant surface | Faux leather upholstery enables wipe-clean maintenance for high-traffic public spaces | |
| Stable fixed base | Solid plinth base eliminates wobble without requiring wall anchoring | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Commercial office public areas | Suitable for office lobbies, breakout zones and waiting areas for casual group seating | |
|---|---|---|
| Food service establishments | Ideal for quick-service restaurant or cafe communal seating with wipe-clean surfaces | |
| Public institution waiting zones | Appropriate for hospital, bank or government building waiting areas with high traffic | |
| Educational facility common spaces | Suitable for university student lounges and library collaborative zones | |
| Retail store customer areas | Usable for retail fitting room waiting zones or customer rest areas | |
| Event venue temporary seating | Suitable for exhibition halls or event spaces requiring reconfigurable seating |
EU Market Access Requirements* EN Standards
| Seating furniture strength standard | EN 12520:2015 | |
|---|---|---|
| Upholstered furniture flammability | EN 1021:2014 | |
| Furniture surface emission standard | EN 16516:2017 |
US and Canada office-furniture standards
| Lounge seating durability standard | ANSI/BIFMA X2022 | |
|---|---|---|
| Furniture stability standard | ANSI/BIFMA X2017Clause 7 |
Standards applicable to China-market projects
| Upholstered furniture safety standard | GB 28007 | |
|---|---|---|
| Formaldehyde emission limit | GB 18584 | |
| Furniture durability test standard | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Upholstered furniture safety standard: GB 28007; 2. Formaldehyde emission limit: GB 18584; 3. Furniture durability test standard: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
