Automatic mm / inch conversion · Core engineering specifications
| Backrest height above seat surface | 360 mm | |
|---|---|---|
| Ground clearance under seat base | 30 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Per-seat static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 72 kg | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Design service life | 8 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest upholstery | 1.2mm thick matte faux leather | |
|---|---|---|
| Seat cushion core | High-resilience polyurethane foam | |
| Backrest cushion core | Medium-density polyurethane foam | |
| Internal structural frame | 18mm thick multi-layer engineered wood panel | |
| Base support feet | Brushed stainless steel cylindrical feet | |
| Upholstery stitching | High-tenacity polyester bonded thread | |
| Backrest signage | UV-printed white text and accessibility pictograms | |
| Panel edge detailing | Piped upholstery edges | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Modular sectional design | Freestanding two-module configuration | |
|---|---|---|
| Integrated priority seating signage | Backrest printed with courtesy seat text and 4 accessibility icons | |
| Elevated base design | 30mm ground clearance under seat | |
| Anti-slip floor contact | Each foot fitted with non-marking rubber glide | |
| Extended side seating | Backless ottoman provides additional flexible seating or temporary bag rest | |
| Stain-resistant upholstery surface | Non-porous faux leather finish | |
| Fixed upright back support | 98 degree backrest angle | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Hospital and clinic waiting areas | Durable upholstery and priority signage suit patient and visitor waiting use | |
|---|---|---|
| Government service hall lobbies | Formal two-tone design meets public space functional and signage requirements | |
| Bank and financial service waiting zones | Easy-clean surface and modular layout fit high-foot-traffic customer areas | |
| Office building reception lounges | Compact footprint provides casual guest seating near entry points | |
| Public transport station waiting areas | Robust construction supports high-frequency daily public use | |
| Accessible public facility seating | Standard seat height and priority marking comply with universal access guidance |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
