Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 850 x 1200 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Static load capacity | 160 kg | |
|---|---|---|
| Unit net weight | 38 kg | |
| Fabric abrasion resistance | 50000 Martindale cycles | |
| Foam density (seat cushion) | 45 kg/m³ | |
| Foam density (backrest) | 35 kg/m³ | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer privacy shell upholstery | Teal woven polyester fabric | |
|---|---|---|
| Seat cushion upholstery | Light gray woven polyester fabric | |
| Backrest inner upholstery | Dark gray woven polyester fabric | |
| Internal padding | High-density polyurethane foam | |
| Structural frame | 1.5mm thick powder-coated black steel | |
| Side table top | 18mm thick matte white MDF with laminate finish | |
| Under-seat support webbing | Elasticated polypropylene webbing | |
| Foot pads | Non-slip rubber | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| High-back privacy wing | Enclosed side and upper back panels block peripheral distraction for focused individual seating | |
|---|---|---|
| Integrated swivel-free side table | Fixed-position round table on right arm side for placing devices and beverages without separate furniture | |
| Fixed sled base | Stable low-profile steel base eliminates rocking and prevents tipping during normal use | |
| Fixed angled backrest | 105-degree recline angle for relaxed upright seating suitable for reading or casual work | |
| Padded integrated armrests | Upholstered arm pads at 220mm above seat for arm support during extended seating | |
| Floor protection | Rubber foot caps on all leg ends prevent scratching hard flooring and reduce movement noise | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Packaged carton count | 1 unit per carton | |
|---|---|---|
| Packaged carton dimensions | 950 x 900 x 800 mm | |
| Packaged gross weight | 44 kg | |
| Assembly time | 25 minutes | |
| 20ft GP container loading capacity | 38 units | |
| 40ft HQ container loading capacity | 92 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set |
Recommended spaces / users / usage modes
| Office open-plan quiet zones | Provides semi-enclosed individual seating for focused work or private calls without full office pods | |
|---|---|---|
| Corporate lounge waiting areas | Creates comfortable separated seating for visitors in reception or break spaces | |
| Coworking space focus nooks | Offers individual semi-private seats for members needing reduced distraction | |
| Hotel lobby breakout areas: Supports casual seating for guests reading or using personal devices | Matches durable commercial upholstery grade | |
| Library and study spaces | Provides quiet individual seating with built-in table space for materials | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
