Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 3600 x 1400 x 760 mm | |
|---|---|---|
| Seat height from floor | 430 mm | |
| Seat depth per curved segment | 650 mm | |
| Backrest height above seat surface | 330 mm | |
| Individual curved seat segment width (outer arc) | 1200 mm | |
| Inner open arc width between left and right seating ends | 1200 mm | |
| Outer side panel thickness | 120 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest cushion thickness | 100 mm | |
| Clearance under seat base | 10 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total seating capacity | 6 persons | |
|---|---|---|
| Static load per seat | 150 kg | |
| Total assembled product weight | 180 kg | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Seat foam density | 40 kg/m³ | |
| Back foam density | 30 kg/m³ | |
| Foam rebound rate | 55% | |
| Warranty period | 3 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery fabric | Woven commercial-grade polyester fabric | |
|---|---|---|
| Seat cushion core | High-resilience polyurethane foam | |
| Backrest cushion core | Medium-density polyurethane foam | |
| Inner structural frame | Kiln-dried solid wood with plywood reinforcement | |
| Base upholstery panel | Hard plywood wrapped in matching grey fabric | |
| Floor protection glides | Nylon non-marking leveling glides | |
| Inter-module connection hardware | Powder-coated steel bracket connectors | |
| Fabric seam construction | Double-stitched seams with polyester thread | |
| Fire retardant treatment | Optional CAL 117 compliant foam barrier | |
| Frame edge treatment | 10mm thick polyurethane foam edge wrap under upholstery | |
| Fire barrier layer | Polyester fire retardant interliner | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration | Segments can be connected or separated to form curved, linear, or circular seating layouts | |
|---|---|---|
| Backrest support layout | Mid-back cushions are integrated on two outer end modules, central two segments are backless bench seats | |
| Leveling adjustment | Concealed glides at each module base allow 5mm height adjustment to compensate for uneven floors | |
| Fixed upholstery design | Cushions are integrated into the module frame, no removable loose cushions | |
| Armless open entry | All seat positions have no armrests, allowing entry from the inner open side of the U-configuration | |
| Wall-free placement | Fully upholstered on all visible outer surfaces, suitable for placement in center of open spaces with no wall required | |
| Static stable configuration | When connected, modules form a rigid U-shape with no tilt or movement under normal seated load | |
| Fixed integrated cushion design | Cushions are bonded to the module frame with no removable loose cushions | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 3 pieces | |
|---|---|---|
| Individual carton dimensions (per module) | 1250 x 700 x 800 mm | |
| Total gross shipping weight | 210 kg | |
| Total shipping volume (CBM) | 2.1 m³ | |
| Assembly time (2 persons) | 40 minutes | |
| 20ft GP container loading quantity | 24 sets | |
| 40ft HQ container loading quantity | 60 sets | |
| Packaging material | 5-layer corrugated carton with PE foam wrap and corner protectors | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Office lobby and reception areas | Curved U-shape creates an enclosed waiting zone that accommodates small groups of visitors while maintaining open sight lines to reception desks | |
|---|---|---|
| Corporate breakout and collaboration zones | Open armless design supports both casual individual work and small team discussions without restricting movement between seats | |
| Public building waiting areas | Stain-resistant commercial fabric and fixed cushion design reduces maintenance requirements for high foot traffic areas including hospitals, universities and government service halls | |
| Open plan office informal meeting spaces | Low back height does not block sight lines across open workspaces, while providing sufficient support for 60 minute meetings | |
| Educational institution common rooms | 6-seat capacity supports group study and student social activities, durable fabric withstands heavy daily use | |
| Event and exhibition temporary seating | Modular segments can be separated to create different seating layouts for event spaces, and reconnected for permanent installation | |
| High-rise office lobby and reception areas | Curved C-shape creates a semi-enclosed waiting zone that accommodates small groups of visitors while maintaining open sight lines to reception desks | |
| Exhibition and event flexible seating | Modular segments can be separated to create linear or scattered seating layouts for event spaces, and reconnected into curved formations for permanent installation |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Strength, durability and safety requirements applicable for non-domestic lounge seating, including static load, fatigue test, and stability requirements for public area use | |
|---|---|---|
| EN 1021-1:2014 | Ignition resistance requirements applicable for upholstered furniture, covering smouldering cigarette ignition resistance for commercial installations |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Performance standard applicable for lounge and public seating, including vertical load, backrest strength, and stability test requirements for commercial office and public space installations |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable for wooden frame upholstered furniture, including dimensional stability, structural strength, and safety edge requirements for public seating | |
|---|---|---|
| GB 20286-2006 | Fire performance requirements applicable for upholstered furniture used in public assembly spaces with high occupant load, requiring flame retardant upholstery and cushion materials | |
| GB/T 16799-2008 | Performance requirements applicable for upholstery fabrics used on furniture, including color fastness, pilling resistance, and abrasion performance for commercial use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable for wooden frame upholstered furniture, including dimensional stability, structural strength, and safety edge requirements for public seating; 2. GB 20286-2006: Fire performance requirements applicable for upholstered furniture used in public assembly spaces with high occupant load, requiring flame retardant upholstery and cushion materials; 3. GB/T 16799-2008: Performance requirements applicable for upholstery fabrics used on furniture, including color fastness, pilling resistance, and abrasion performance for commercial use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
