Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2200 x 970 x 720 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat depth | 640 mm | |
| Individual seat module width | 900 mm | |
| Backrest bolster diameter | 150 mm | |
| Backrest stem height above seat | 270 mm | |
| Backrest stem diameter | 12 mm | |
| Base bevel angle from vertical | 15 degrees | |
| Base ground clearance | 5 mm | |
| Backrest total width per seat | 600 mm | |
| Seat foam thickness | 120 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Overall static load capacity | 362 kg | |
|---|---|---|
| Product net weight | 70 kg | |
| Seat foam density | 28 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Fabric abrasion resistance (Martindale) | 30000 cycles | |
| Fabric weight | 300 gsm | |
| Seam stitch pitch | 30 mm/10 stitches | |
| Cushion shape recovery time | 72 hours | |
| Warranty period | 3 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat base outer upholstery | Polyester woven fabric, matte finish, off-white and dark green two-tone | |
|---|---|---|
| Internal support frame | Kiln-dried engineered hardwood, corner-blocked joinery | |
| Seat core fill | 28D high-resilience polyurethane foam, no coil springs | |
| Backrest bolster fill | High-density polyurethane foam, cylindrical shape | |
| Backrest support stems | Powder-coated steel tubular posts, matte silver finish | |
| Base bottom glides | Non-marking felt pads, floor-protective | |
| Seat support layer | 10mm thick hardboard panel, fully upholstered | |
| Modular connecting hardware | Zinc-plated steel connector brackets, invisible external finish | |
| Backrest mounting sockets | Reinforced plastic inserts, integrated into seat base | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Modular seat configuration | Two independent seat sections connect via hidden steel brackets to form a straight platform | |
|---|---|---|
| Backrest position adjustment | Stem-mounted bolsters insert into seat sockets, allowing 100mm vertical height adjustment and 360-degree rotation | |
| Backrest removal option | Cylindrical backrests can be fully removed to convert the unit to an open bench/platform | |
| Floor protection function | Felt bottom glides prevent floor scratching on hard surface flooring without adjustable feet | |
| Two-color design option | Two-tone off-white and dark green upholstery provides reversible color-block visual customization | |
| Modular expansion compatibility | Units can be connected end-to-end to create longer linear lounge seating arrangements | |
| Seating surface use | Low deep seat supports upright seated or relaxed reclined lounge postures for two adults | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential living room lounge | Low-profile design works as casual two-seat seating for open-plan modern living spaces | |
|---|---|---|
| Office reception/waiting area | Compact two-seat form provides guest seating in minimalist corporate reception zones | |
| Boutique hotel lobby lounge | Two-tone contemporary style complements high-end hospitality public space design | |
| Open-plan workspace breakout area | Provides relaxed informal seating for employee breaks or small collaborative discussions | |
| Residential bedroom end-of-bed bench | Low profile works as a foot-of-bed seating option with removable backrests | |
| Showroom display seating | Faceted angular silhouette serves as a decorative statement piece for furniture or interior showrooms |
EU Market Access Requirements* EN Standards
| EN 1728:2012 | Furniture - Seating - Test methods for strength and durability, applicable to structural load validation | |
|---|---|---|
| EN 1021-1:2014 | Furniture - Assessment of flammability of upholstered furniture, ignition source smouldering cigarette, applicable to fire safety checks |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal wood frame quality checks | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable to formaldehyde emission checks | |
| GB/T 19826-2017 | Technical specifications for upholstered furniture sofas, applicable to structural performance and durability checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal wood frame quality checks; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable to formaldehyde emission checks; 3. GB/T 19826-2017: Technical specifications for upholstered furniture sofas, applicable to structural performance and durability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
