Automatic mm / inch conversion · Core engineering specifications
| 2-seater sofa unit overall dimensions | 1600 x 750 x 720 mm | |
|---|---|---|
| single seat module width | 800 mm | |
| seat cushion height from floor | 450 mm | |
| backrest total height above seat | 300 mm | |
| armrest width | 150 mm | |
| seat cushion depth | 600 mm | |
| steel base ground clearance | 120 mm | |
| matching side table overall dimensions | 600 x 600 x 420 mm | |
| table top thickness | 30 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| 2-seater sofa unit net weight reference | 55 kg | |
|---|---|---|
| single seat static load capacity | 150 kg | |
| upholstery abrasion resistance reference | 50000 cycles | |
| foam compression set reference | 10% | |
| upholstery abrasion resistance (Martindale) | 50000 cycles | |
| seat foam compression set (72h/40% compression) | 10% | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat | |
| Upholstery Seam Pitch | 4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| seat and backrest upholstery face | Turquoise and black two-tone faux leather (PVC) | |
|---|---|---|
| seat cushion core fill | High-density polyurethane foam | |
| sofa inner structural frame | Particle board with reinforced wooden battens | |
| sofa support base legs | Chrome-finished powder-coated steel U-shaped frame | |
| side table top surface | White matte laminate over MDF substrate | |
| side table support structure | Silver powder-coated steel U-shaped leg frame | |
| sofa stitching and seams | Synthetic thread lock-stitched seams at upholstery joints | |
| base foot glides | Plastic anti-slip glides under steel leg ends | |
| seat base and lower side upholstery | Black matte PVC faux leather with 0.8mm thickness | |
| backrest and armrest upper upholstery | Turquoise matte PVC faux leather with 0.8mm thickness | |
| backrest core fill | 30kg/m³ medium-density polyurethane foam | |
| sofa support base frame | Chrome-finish powder-coated steel U-shaped sled frame with 40 x 40mm rectangular tube |
Adjustment / rotation / tilt / mobility / storage features
| modular reconfiguration | Individual seat modules can be arranged into 1-seater, 2-seater, linear bench or L-shaped layouts | |
|---|---|---|
| dual-sided backrest use | Tall upholstered back panels on end modules provide back support for seating facing either direction | |
| acoustic dampening contribution | Thick padded upholstery reduces ambient noise reflection in open office areas | |
| easy floor maintenance | 120mm open ground clearance under steel sled base allows robot vacuum and mop access | |
| contract-grade durability | Reinforced frame and abrasion-resistant faux leather support daily use in high-traffic reception areas | |
| dual-direction seating support | Padded back panels on end and middle modules provide lumbar support for users seated facing either side of the unit | |
| floor cleaning accessibility | 120mm open ground clearance under the steel sled base accommodates standard robot vacuums and mop equipment | |
| ambient acoustic dampening | 100mm thick padded seat cushions and 150mm thick backrests reduce hard surface noise reflection in open plan spaces | |
| stain-resistant surface maintenance | Smooth PVC faux leather upholstery can be wiped clean with neutral detergent for daily care | |
| sled base stability | Continuous U-shaped steel sled frame distributes load evenly and prevents tipping under 150kg per seat static load | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| 2-seater sofa unit packaging | 1 flat carton per unit, 1680 x 830 x 380 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| corporate office reception area | Designed for waiting and informal meeting zones in office lobbies where visitors and employees sit for short to medium periods | |
|---|---|---|
| open plan office breakout zone | Suitable for casual collaboration, phone calls or short rest breaks between workstations | |
| co-working space lounge area | Flexible reconfiguration supports changing event layouts, group discussions or individual quiet work on side tables | |
| staff lounge and cafeteria seating | Durable faux leather surface is easy to wipe clean for food and drink areas | |
| library and reading room seating | Padded upholstery offers comfortable seating for extended reading while maintaining a professional appearance | |
| corporate office reception lobby | Designed for visitor waiting and short informal meetings in office front-of-house areas, with modular layout adapting to 50sqm lobby spaces | |
| co-working space shared lounge | Flexible reconfiguration supports changing event layouts, group discussions of 8 people or individual quiet work for up to 2 hours per sitting | |
| staff lounge and pantry seating | Wipe-clean PVC upholstery is suitable for food and drink areas, with 150kg per seat load capacity supporting all-staff break periods |
EU Market Access Requirements* EN Standards
| upholstered furniture safety | EN 12520:2015 applies to strength, durability and stability of seating for non-domestic use | |
|---|---|---|
| flammability of upholstered seating | EN 1021:2014 cigarette test and EN 1021:2014 match flame test for contract environments | |
| formaldehyde for wood panels | EN 2018 P2 grade particle board and EN 317 MDF recommended for indoor office furniture | |
| contract seating strength and durability | EN 12520:2015 applies to strength, durability and stability of seating for non-domestic use | |
| upholstered seating flammability | EN 1021:2014 cigarette test and EN 1021:2014 match flame test for contract environments | |
| wood-based panel formaldehyde emission | EN 13986:2004 Class E1 requirement for particle board and MDF used in indoor office furniture |
US and Canada office-furniture standards
| contract seating durability | Recommended references: ANSI/BIFMA X2020 | |
|---|---|---|
| office furniture formaldehyde | ANSI/BIFMA E2019 formaldehyde and VOC emission limits for wood-based components |
Standards applicable to China-market projects
| upholstered furniture safety | GB 28007 applies to stability, flammability and harmful substance limits for public use upholstered furniture | |
|---|---|---|
| formaldehyde emission for wood-based panels | GB 18580 E1 grade required for internal particle board and MDF components | |
| metal coating corrosion resistance | GB/T 10125 neutral salt spray test 48h no rust for chrome-plated steel legs | |
| upholstered furniture safety general requirements | GB 28007 applies to stability, flammability and harmful substance limits for public use upholstered furniture | |
| wood-based panel formaldehyde emission | GB 18580 E1 grade required for internal particle board and MDF components | |
| upholstered furniture foam flame retardancy | GB 20286 Class B1 flame retardant rating required for seat and back foam in public places |
This product must meet the following technical requirements: 1. upholstered furniture safety: GB 28007 applies to stability, flammability and harmful substance limits for public use upholstered furniture; 2. formaldehyde emission for wood-based panels: GB 18580 E1 grade required for internal particle board and MDF components; 3. metal coating corrosion resistance: GB/T 10125 neutral salt spray test 48h no rust for chrome-plated steel legs; 4. upholstered furniture safety general requirements: GB 28007 applies to stability, flammability and harmful substance limits for public use upholstered furniture; 5. wood-based panel formaldehyde emission: GB 18580 E1 grade required for internal particle board and MDF components; 6. upholstered furniture foam flame retardancy: GB 20286 Class B1 flame retardant rating required for seat and back foam in public places; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
