Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 720 x 760 x 1220 mm | |
|---|---|---|
| Lumbar pillow dimensions | 320 x 240 x 80 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Static seat load capacity | 160 kg | |
|---|---|---|
| Product net weight | 28 kg | |
| Fabric abrasion resistance | 50000 Martindale cycles | |
| Foam density (seat) | 45 kg/m³ | |
| Foam density (back/panels) | 30 kg/m³ | |
| Foam indentation load deflection (seat) | 180 N | |
| Recommended daily use duration | 8 hours | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat cushion upholstery | Polyester-blend woven fabric | |
|---|---|---|
| Back/side privacy panel upholstery | Matching polyester-blend woven fabric | |
| Seat cushion core | High-resilience polyurethane foam | |
| Back/side panel core | Medium-density polyurethane foam over plywood substrate | |
| Lumbar pillow | Polyester fiberfill wrapped foam core | |
| Support frame | Matte white powder-coated 25mm diameter steel tubing | |
| Frame finish | Epoxy polyester powder coating | |
| Leg feet | Injection-molded non-marking polypropylene glides | |
| Seam construction | Reinforced stitched seams with 8mm stitch pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| High-back privacy enclosure | Three-sided tall padded panels block line of sight from sides and rear | |
|---|---|---|
| Integrated lumbar support | Contoured fixed pillow aligns with lower back for upright seated support | |
| Non-adjustable fixed seat geometry | 12-degree backward seat tilt for relaxed upright posture | |
| Floor protection glides | Fixed non-marring glides prevent scuffing on hard flooring surfaces | |
| Modular alignment capability | Flat side panel edges allow adjacent placement in linear or clustered seating groups | |
| Fixed non-reclining structure | Rigid integrated frame prevents unintended movement or tilting during use | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Open office quiet zones | Provides semi-private individual seating for focused work or short breaks | |
|---|---|---|
| Co-working space lounge areas | Supports solo work, casual calls or short rest between meetings | |
| Corporate lobby waiting areas | Offers comfortable, visually separated seating for visitors waiting for appointments | |
| Public library quiet reading corners | Creates individual reading nooks without full partition installation | |
| Healthcare facility waiting zones | Easy to clean upholstery and stable frame suit high-traffic public waiting areas | |
| Hotel lobby lounge zones | Complements modern hospitality interiors for guest seating and casual gatherings | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
