Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 3600 x 1410 x 760 mm | |
|---|---|---|
| Seat height from floor | 440 mm | |
| Seat depth (central seating zone) | 680 mm | |
| Chaise end depth (each extended end) | 1100 mm | |
| Seat cushion thickness | 220 mm | |
| Backrest height above seat | 320 mm | |
| Clearance under sofa base | 30 mm | |
| Single seat module width | 900 mm | |
| Throw pillow size (matching set) | 450 mm diameter/width | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total static load capacity | 1000 kg | |
|---|---|---|
| Seat foam density | 30D | |
| Foam rebound rate | 60% | |
| Fabric Martindale abrasion resistance | 30000 cycles | |
| Seating capacity | 5 people | |
| Frame static load warranty duration | 5 years | |
| Upholstery and cushion warranty duration | 2 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery fabric | Cream textured bouclé polyester, 400gsm weight | |
|---|---|---|
| Seat cushion fill | 30D high-density polyurethane foam with fiber wrap | |
| Back cushion fill | 25D polyurethane foam blended with polyester fiber | |
| Internal frame | Kiln-dried solid pine wood, 30mm section thickness | |
| Support webbing | 50mm wide elastic webbing, 80mm spacing under seat | |
| Base support feet | Black matte powder-coated steel, hidden low-profile design | |
| Stitch construction | Concealed overlock seams, 8 stitches per inch | |
| Included throw pillows | Matching textured fabric covers, polyfiber fill, 3 included pieces | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
| Modular connection system | Metal bracket connectors between adjacent segments | |
|---|---|---|
| Double chaise layout | Extended reclining surfaces at both left and right ends | |
| Rounded edge design | Fully upholstered soft edges with no exposed hard frames | |
| Low-profile base design | Minimal floor clearance for a grounded, sculptural silhouette | |
| Spot-clean upholstery | Stain-resistant fabric finish for easy maintenance | |
| Fixed cushion positioning | Non-removable seat and back cushions secured to frame | |
| Armless continuous curve | Uninterrupted seating surface without protruding armrests | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Residential open-plan living rooms | Fits curved conversation zones for casual family and guest seating | |
|---|---|---|
| Modern hotel lobby lounge areas | Sculptural form creates welcoming soft seating for guest waiting spaces | |
| High-end office reception zones | Low-profile neutral design supports relaxed visitor waiting areas | |
| Luxury villa entertainment spaces | Double chaise layout accommodates small groups for casual gatherings | |
| Contemporary showroom display areas | Cream neutral finish complements curated modern interior design schemes | |
| Open lounge breakout areas | Armless curved design supports flexible, informal collaborative seating |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
