| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 1200 x 430 mm | |
|---|---|---|
| Single rounded seat lobe diameter | 700 mm | |
| Connecting central section width | 400 mm | |
| Seat surface height from floor | 430 mm | |
| Per-lobe curved side cutout depth | 150 mm | |
| Upholstered side panel thickness | 80 mm | |
| Inner concave curve radius | 350 mm | |
| Base contact width per lobe | 680 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net product weight | 36 kg | |
|---|---|---|
| Static load capacity per seat lobe | 150 kg | |
| Seating capacity (adult users) | 3 | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Foam indentation load deflection (seat) | 40 kg/m3 | |
| Anti-tip stability factor | 1.8 | |
| Surface colorfastness to rubbing | Grade 4 | |
| Maximum seating capacity (adult users) | 3 | |
| Seat foam indentation load deflection | 40 kg/m3 | |
| Surface colorfastness to dry rubbing | Grade 4 |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer seat upholstery (purple sections) | Woven polyester commercial fabric | |
|---|---|---|
| Recessed side upholstery (gold sections) | Matching woven polyester commercial fabric | |
| Internal support frame | 18 mm thick birch plywood | |
| Seat padding foam | 40 kg/m3 high-resilience polyurethane foam | |
| Side panel padding foam | 20 mm thick polyurethane foam | |
| Bottom base layer | Black non-slip non-woven fabric | |
| Seam construction | Reinforced stitched seams with 8 mm stitch pitch | |
| Internal adhesive and fasteners | Low-VOC construction adhesive and staples | |
| Edge finishing | Hidden turned-edge upholstery construction | |
| Floor contact glides | 5 mm thick self-adhesive felt glides fitted to bottom of each lobe | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Three-directional multi-user seating with 120-degree separation between lobes | |
|---|---|---|
| Surface functionality | Flat padded tops support use as temporary side tables for items like laptops, drinks or reading materials | |
| Fixed floor installation | Free-standing non-mobile unit with non-slip base | |
| Modular compatibility | Standalone unit compatible with matching curved soft seating modules for larger lounge configurations | |
| Maintenance feature | Upholstered surface allows spot cleaning with commercial fabric cleaner | |
| Safety design | Fully rounded soft edges with no exposed hard corners | |
| Floor mounting design | Free-standing non-mobile unit with non-slip base | |
| Color matching capability | Upholstery available in customer-specified commercial fabric colorways on request | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 1850 x 1250 x 480 mm | |
| Gross shipping weight | 42 kg | |
| Shipping volume per unit | 1.11 CBM | |
| Assembly time on site | 10 minutes | |
| 20ft GP container loading quantity | 24 units | |
| 40ft HQ container loading quantity | 60 units | |
| Protective packaging materials | 5 mm thick corner protectors, 20 mm EPE foam wrap, double-walled corrugated carton | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Office open plan breakout areas | Provides casual flexible seating for employee breaks, informal meetings or waiting zones with distinctive colorful design that fits modern office aesthetics | |
|---|---|---|
| Educational institution common spaces | Suitable for school lobbies, library lounge areas or student collaboration zones, with soft rounded edges and durable construction for high student traffic | |
| Public waiting and reception areas | Ideal for creative agency, retail or hospitality reception zones, offering multi-directional seating for visitors with strong visual identity | |
| Children's activity and play spaces | Soft padded construction with no sharp corners provides safe seating for playrooms, daycare centers or family public facilities | |
| Event and exhibition temporary seating | Lightweight free-standing design allows easy repositioning for trade shows, pop-up events or exhibition spaces needing flexible, eye-catching seating | |
| Recommended complementary configuration | Pair with matching cylindrical single ottomans and low-height coffee tables to create extended flexible lounge clusters for larger open spaces | |
| Retail customer waiting zones | Suitable for apparel store, beauty salon or boutique customer waiting areas, with stain-resistant polyester fabric that supports regular spot cleaning for high-turnover retail environments | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture - Strength, durability and safety for non-domestic seating, applicable for static load and stability testing of commercial lounge seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture flammability - cigarette ignition resistance, minimum fire safety requirement for commercial soft seating | |
| EN 71-3:2019 | Toy safety migration of certain elements, recommended additional compliance if the unit is used in children's activity or education spaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Standard for lounge and public seating, covering static load, stability and durability requirements for commercial public lounge ottomans |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to the internal plywood frame structure, covering dimensional tolerance and structural strength | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wood furniture, applicable for formaldehyde emission limits from internal frame and foam materials | |
| GB/T 19817-2005 | Upholstered furniture anti-durability and safety requirements, applicable for structural stability and load performance testing | |
| GB 20286-2006 | Flame retardant requirements for public place furniture, recommended specification for units installed in high-traffic public lounge areas |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to the internal plywood frame structure, covering dimensional tolerance and structural strength; 2. GB 18584-2001: Limit of harmful substances in wood furniture, applicable for formaldehyde emission limits from internal frame and foam materials; 3. GB/T 19817-2005: Upholstered furniture anti-durability and safety requirements, applicable for structural stability and load performance testing; 4. GB 20286-2006: Flame retardant requirements for public place furniture, recommended specification for units installed in high-traffic public lounge areas; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
