Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 950 x 850 x 1350 mm | |
|---|---|---|
| Seat height from floor | 480 mm | |
| Seat width | 700 mm | |
| Seat depth | 600 mm | |
| Back height from seat | 870 mm | |
| Armrest height from seat | 200 mm | |
| Seat cushion thickness | 130 mm | |
| Back cushion thickness | 100 mm | |
| Plinth base height | 120 mm | |
| Gold trim width | 5 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static load capacity | 136 kg | |
|---|---|---|
| Net product weight | 70 kg | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Foam rebound rate | 60% | |
| Fabric abrasion resistance | 50000 double rubs | |
| Acoustic privacy attenuation | 15 dB | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery (cream seat/inner back) | Matte woven polyester fabric | |
|---|---|---|
| Outer side panel upholstery (terracotta) | Matte woven polyester fabric | |
| Internal structural frame | 18mm thick engineered plywood frame | |
| Seat cushion core | High-resilience polyurethane foam with Dacron wrap | |
| Back cushion core | Dual-layer polyurethane foam with fiber wrap | |
| Decorative edge trim | Gold-toned polished metal trim | |
| Integrated armrest structure | Upholstered frame matched to seat/back padding | |
| Plinth base | Fully upholstered rigid frame with anti-slip floor glides | |
| Central control panel | Matte grey plastic interface plate | |
| Seam stitching | Heavy-duty polyester thread with 8mm stitch pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Wraparound high back design | Creates semi-enclosed private seating space reducing visual distraction | |
|---|---|---|
| Integrated padded armrests | Provide continuous arm support flush with seat and back structure | |
| Central control interface | Located between dual back cushions for function adjustment | |
| Plinth base support | Delivers low-profile stable seating without exposed legs | |
| Anti-slip base glides | Protect floor surfaces and prevent unintended chair movement | |
| Segmented dual back cushions | Provide targeted lumbar and mid-back support for relaxed seated posture | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office open plan focus areas | Provides semi-private seating for individual rest or quiet work without enclosed pods | |
|---|---|---|
| Executive office lounge zones | Serves as high-end guest or executive relaxation seating in private offices | |
| High-end reception waiting areas | Delivers premium visual appeal and comfortable private waiting seating | |
| Co-working space breakout zones | Creates individual semi-private rest spots for members between tasks | |
| Luxury residential living rooms | Functions as a statement accent chair for modern residential interiors | |
| Hotel lobby lounge areas | Provides durable, stylish guest seating with private nook feel in public spaces | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-2:2018 | Office seating strength/durability, applicable for commercial lounge use | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture cigarette ignition resistance requirement |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge seating structural performance and durability standard | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability criteria for commercial specification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame structure | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for engineered wood frame components | |
| GB/T 19843-2005 | Test methods for upholstered furniture static and fatigue load |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structure; 2. GB 18580-2017: Formaldehyde emission limits for engineered wood frame components; 3. GB/T 19843-2005: Test methods for upholstered furniture static and fatigue load; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
