Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 1800 x 750 x 720 mm | |
|---|---|---|
| Single armchair overall dimensions | 750 x 750 x 720 mm | |
| Rectangular coffee table overall dimensions | 1200 x 600 x 420 mm | |
| Square side table overall dimensions | 550 x 550 x 550 mm | Standard side table height for sofa arm level alignment, sized to fit next to single chairs | |
| 3-seater sofa seat height | 430 mm | |
| 3-seater sofa seat depth | 550 mm | |
| 3-seater sofa backrest height | 300 mm | |
| Sofa armrest height | 580 mm | |
| Coffee table tempered glass thickness | 10 mm | |
| Metal sofa leg diameter | 30 mm | |
| 3-seater sofa seat height (floor to seat top) | 430 mm | |
| 3-seater sofa seat depth (front edge to backrest inner face) | 550 mm | |
| 3-seater sofa backrest height (seat top to backrest top) | 300 mm | |
| 3-seater sofa seat width (inner arm to inner arm) | 1620 mm | |
| Sofa armrest height (floor to armrest top) | 580 mm | |
| Sofa armrest width | 90 mm |
Net weight / load capacity / users / durability
| 3-seater sofa maximum static load capacity | 360 kg | |
|---|---|---|
| 3-seater sofa unit net weight | 42 kg | |
| Foam compression set resistance reference | ≤5% after 72h at 50% compression | |
| Coffee table maximum static surface load | 60 kg | |
| Foam compression set resistance | 5% | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa upholstery fabric | Woven polyester fabric, medium weight, plain weave finish | |
|---|---|---|
| Sofa seat and back filling | High-density polyurethane foam with layered structure for cushioning | |
| Sofa support frame | Chrome-plated tubular steel frame with sled-style base legs | |
| Coffee/side table top | Tempered clear glass with smooth polished edge | |
| Table support frame | Chrome-plated tubular steel with sled-style base | |
| Sofa back pillows | Matching woven polyester fabric cover with down-blend or foam filling | |
| Metal frame surface finish | Polished chrome electroplating with corrosion-resistant coating | |
| Sofa seat cushion filling | High-density polyurethane foam, single-block layered structure with 35 kg/m³ density grade | |
| Sofa back cushion filling | High-resilience polyurethane foam with soft fiber wrap, encased in fabric liner | |
| Sofa inner support frame | Pine wood solid wood frame with mortise and tenon joint structure, moisture content 12% | |
| Sofa external base frame | Chrome-plated 201-grade tubular steel frame with continuous perimeter sled base and welded leg connections | |
| Sofa seat support system | High-tension polyester webbing grid with 50 mm width straps, spaced 50 mm apart |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Modular 5-seat total set consisting of 1 three-seater sofa and 2 single armchairs | |
|---|---|---|
| Table set matching | Coordinated 2-table set with 1 rectangular coffee table and 1 square side table | |
| Removable back pillows | Loose, repositionable back cushions with fabric covers | |
| Stable metal base design | Sled-style tubular steel base with floor-protective foot pads | |
| Tempered glass table surface | Scratch-resistant, easy-to-clean glass top with high impact resistance | |
| Neutral aesthetic versatility | Minimalist grey upholstery with chrome metal accents | |
| Modular seating configuration | 5 total seat capacity consisting of 1 three-seater sofa and 2 freestanding single armchairs, enabling linear, L-shaped or spaced layout arrangements | |
| Coordinated table set | Matching 2-table set including 1 rectangular coffee table and 1 square side table, aligned with the sofa's metal frame aesthetic | |
| Removable back cushions | Loose, repositionable back cushions with sewn fabric covers, not fixed to the sofa frame | |
| Sled-base stability system | Continuous tubular steel sled base frame with 4 ground contact points per seating unit | |
| Fixed armrest support | Padded upholstered armrests with internal solid wood framing, fixed at 580 mm height from floor | |
| Low-profile base clearance | 120 mm ground clearance under all sofa and table units |
Verified carton / gross weight / assembly / loading data
| Total set packaging carton count | 5 cartons | |
|---|---|---|
| 3-seater sofa reference carton dimensions | 1850 x 550 x 450 mm | |
| Single armchair reference carton dimensions | 780 x 500 x 450 mm | |
| Coffee table reference carton dimensions | 1250 x 650 x 120 mm | |
| Total set reference gross weight | 110 kg | |
| Total set reference volume (CBM) | 0.85 CBM | |
| Single-person assembly time for full set | 90 minutes | |
| Total set reference volume | 0.85 CBM | |
| 20-foot standard container loading quantity | 24 sets | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Corporate office reception area | Ideal for company lobbies and visitor waiting areas, providing comfortable seating for up to 5 guests with coordinated surface space | |
|---|---|---|
| Executive office lounge | Suitable for placement in senior management office suites for informal meetings and guest seating | |
| Co-working space common area | Fits well in shared work environment rest zones, offering flexible seating arrangements for collaboration or break time | |
| Small meeting room seating | Can be used in casual meeting spaces to complement conference tables for less formal discussion sessions | |
| Hotel or serviced office lounge | Appropriate for hospitality commercial spaces requiring durable, modern-looking seating with easy maintenance | |
| Showroom or sales office waiting area | Presents a professional, minimalist aesthetic suitable for client-facing commercial spaces | |
| Corporate office reception lobby | Suitable for company front-desk waiting areas, providing seating for up to 5 visitors with coordinated table space for documents and refreshments | |
| Executive office lounge zone | Appropriate for placement in senior management office suites, supporting informal guest meetings and short rest breaks |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Applicable for seating stability testing for domestic and commercial office seating units | |
|---|---|---|
| EN 13759:2012 | Applicable for safety and performance requirements of office upholstered seating for non-workstation reception use | |
| EN 12520:2015 | Applicable for strength, durability and safety requirements for domestic seating, relevant for reception area light-commercial use seating |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applicable for office seating general safety, durability, and structural performance testing for commercial reception applications | |
|---|---|---|
| ANSI/BIFMA X5.6-2018 | Applicable for lounge and public seating performance standards for commercial office reception spaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for wood-based and upholstered furniture general technical requirements, relevant for foam and structural performance testing of the sofa units | |
|---|---|---|
| GB/T 10357.1-2013 | Applicable for furniture mechanical property testing of seating strength, durability, and stability for commercial office use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for wood-based and upholstered furniture general technical requirements, relevant for foam and structural performance testing of the sofa units; 2. GB/T 10357.1-2013: Applicable for furniture mechanical property testing of seating strength, durability, and stability for commercial office use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
